– 9 –
XS1
RM-Y1010
The Picture Adjustment Menu
The “Picture Adjustment” menu allows you to
alter the picture settings.
To do this:
Press the MENU button and then press OK to
enter this menu. Next, press
v or V to select the
desired option and press OK. Finally, read below
how to operate into each option.
Picture Mode This option allows you to customise the Picture Mode based on the programme
you are watching. After selecting this option press OK. Next, press repeatedly
v
or
V to select:
Live (for live broadcast programmes, DVD and Digital Set Top Box
receivers).
Movie (for films).
Personal (for individual settings).
Once you have selected your desired option, press OK to store.
"Brightness", "Colour" and "Sharpness" level of "Live" and "Movie" mode are fixed on the
factory to get the best picture quality.
Contrast Press B or b to reduce or enhance picture contrast. Next, press OK to store.
Brightness Press B or b to darken or brighten the picture. Next, press OK to store.
This option only appears and can only be adjusted if “Picture Mode” is set to “Personal”.
Colour Press B or b to decrease or to increase color intensity. Next press OK to store.
This option only appears and can only be adjusted if “Picture Mode” is set to “Personal”.
Hue Press B or b to decrease or to increase the green tones. Next press OK to store.
This option only appears for NTSC signal (e.g. USA video tapes).
Sharpness Press B or b to soften or to sharpen the picture. Next press OK to store.
This option only appears and can only be adjusted if “Picture Mode” is set to “Personal”.
,
MENU
continued...
Reset Press OK to reset the picture to the factory preset levels.
Noise This option is set to Auto to automatically reduce the snowy picture visible in the weak broadcast
Reduction signal. However, it can be modified. After selecting this option press
b. Next, press v or V to
select High, Mid, Low or Off. Finally, press OK to store.
Colour Tone This option allows you to alter the tint of the picture. After selecting this option press b. Next, press
repeatedly
v or V to select: Warm (gives the white colours a red tint), Normal (gives the white
colours a neutral tint), Cold (gives the white colours a blue tint). Finally press OK to store.
DRC Mode This option allows you to select the high resolution picture with 4x density for high quality sources
(i.e. DVD player, satellite receiver). This option is set to High Density (recommended for moving
pictures). However it can be modified. After selecting this option, press
b. Next press v or V to
select Progressive (recommended for still images and text).
This option only appears and can only be adjusted if “Picture Mode” is set to “Personal”.
DRC Palette This option allows you to customise the level of detail (Reality) and smoothness (Clarity) for up to
three input sources. After selecting this option press
b. Next, press v or V, to adjust Reality (as
higher as the mark is along the Reality axis, the picture becomes more detailed) and press
B or
b to adjust Clarity (as you move to the right, along the Clarity axis, the picture becomes
smoother). Finally, press OK to store.
This option only appears and can only be adjusted if “Picture Mode” is set to “Personal”.
