– 18 –
XS1
RM-Y1010
Technical Specifications
Panel System:
PDP (Plasma Display Panel)
TV system:
Depending on your country
selection:
B/G/H, D/K, L, I
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Aerial:
75 ohm external terminal for
VHF/UHF
Channel Coverage:
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12, R21-R69
L: F2-F10, B-Q, F21-F69
I: UHF B21-B69
Screen Size:
• KE-P37XS1: 37 inches (approx. 94 cm
measured diagonally)
• KE-P42XS1: 42 inches (approx. 107 cm
measured diagonally)
Display Resolution:
1024 dots (horizontal) x 1024 lines
(vertical)
Power Requirement:
220-240V AC; 50/60 Hz
Power Consumption:
• KE-P37XS1: 312 W
• KE-P42XS1: 370 W
Standby Power Consumption:
1.9 W
Sound Output:
2 x 15 W (RMS)
Dimensions (w x h x d):
• KE-P37XS1:
Approx. 1135 x 692 x 286 mm
• KE-P42XS1:
Approx. 1229 x 753 x 286 mm
Weight:
• KE-P37XS1:
Approx. 37.5 Kg.
• KE-P42XS1:
Approx.
43 Kg.
Rear Terminals:
• AV1: 1/
21-pin Scart connector
(CENELEC standard) including
audio/video input, RGB input,
TV audio/video output.
• AV2: 2/ (SMARTLINK;
selectable)
21-pin Scart connector
(CENELEC standard) including
audio/video input, RGB input,
selectable audio/video output
and SmartLink interface.
• AV3: 3/ (SMARTLINK;
selectable)
21-pin Scart connector
(CENELEC standard) including
audio/video input, S video input,
selectable audio/video output
and Smartlink interface.
• AV4:
• 4: Y:1 Vp-p, 75 ohms,
0.3V negative sync
PB:0.7 Vp-p, 75 ohms
PR:0.7 Vp-p, 75 ohms
• 4: audio input (phono
jacks)
500 m Vrms (100%
modulation),
Impedance: 47 kilo
ohms
• AV MOUSE: minijack
• audio outputs (Left/Right) -
phono jacks
• Sub Woofer output (phono
jack)
• Aerial connector (RF In)
Left side:
• Memory Stick Slot
Right side Terminals:
• AV5:
• 5: S video input (4-pin
mini DIN):
Y: 1 Vp-p, 75-ohms
unbalanced, sync
negative
C: 0.286 Vp-p (Burst
signal), 75 ohms
• 5: video input (phono
jack):
1 Vp-p, 75-ohms
unbalanced, sync
negative
• 5: audio input (phono
jacks):
500 m Vrms,
Impedance: 47 kilo
ohms
• headphones jack
Accessories supplied:
• One Remote Control (RM-Y1010)
• Two size AA batteries (R03 type)
• One Coaxial Cable
• One AV Mouse
• One Mains Leads (Type C-4)
• One Mains Leads (Type BF)
• One Mains Leads (Type C-5)
Main leads Type BF and
Type C-5 may not be supplied
depending on the country.
• One Cleaning cloth
• One Clump Belt.
• Two Anchor attachments.
Other features:
• Teletext, Fastext, TOPtext
• NexTView
• Sleep Timer
• SmartLink (direct link between
your TV set and a compatible
VCR or DVD recorder. For more
information on Smartlink, please
refer to the Instruction Manual of
your VCR or DVD recorder).
• TV system Autodetection
• Dolby Virtual
• BBE Digital
• ACI (Auto Channel Installation)
• Auto Format
• DRC
®
(Digital Reality Creation)
• Remote Control with learning
functions.
• Memory Stick (reader).
S
S
Design and specifications are subject to change without notice.
This instruction manual has been printed on:
Ecological Paper - Totally Chlorine Free
Troubleshooting
Here are some simple solutions to problems which may affect the picture and sound.
Problem Possible solution
No picture
No picture (screen is dark) and no sound. • Check the aerial connection.
• Connect the TV to the mains, and press the power switch on the
right side of the TV set.
• If the (standby) indicator is on, press AUX/VIDEO on the
remote control.
The TV turns off automatically. (The TV
enters the standby mode.)
• Check if the Sleep Timer is activated (page 25).
• Check if Auto Shutoff is activated (page 25).
No picture or no menu information from
equipment connected to the Scart
connector.
• Check that the optional equipment is on and press the button
repeatedly on the remote control until the correct input symbol is
displayed on the screen (page 40).
• Check the connection between the optional equipment and the TV.
Poor picture/Unstable picture.
Double images or ghosting. • Check aerial/cable connections.
• Check the aerial location and direction.
Only snow and noise appears on
the screen.
• Check if the aerial is broken or bent.
• Check if the aerial has reached the end of its serviceable life. (3-5
years in normal use, 1-2 years at the seaside)
Dotted lines or stripes. • Keep the TV away from electrical noise sources such as cars,
motorcycles, or hair-dryers.
No colour on colour programmes. • Using the menu system, select the “Picture Adjustment” menu and
select “Reset” to return to the factory settings (page 19).
• If you set the Power Saving function to “Reduce,” picture colours
may become dimmer (page 22).
Some tiny black points and/or bright
points on the screen.
• The picture of the display is composed of pixels. Tiny black points
and/or bright points (pixels) on the screen, do not indicate a
malfunction.
The picture is too bright.
Picture (stripe) noise.
• Using the menu system, select the “Picture Adjustment” menu and
select “Picture Mode” Then select the desired picture mode (page
18).
• Make sure that the aerial is connected using the supplied coaxial
cable.
• Keep the aerial cable away from other connecting cords.
• Do not use 300-ohm twin lead cables as interference may occur.
Poor picture (white saturation) when
viewing a signal from Scart connector
3/ .
• Make sure that the output signal of the equipment connected to the
Scart connector 3/ is not an RGB signal. If it is an RGB
signal, please connect the equipment to Scart 1/ or
2/ .
S
S
TV
continued...
