Sony KE-P42XS1 [6/64] Led error code
![Sony KE-P42XS1 [6/64] Led error code](/views2/1313301/page6/bg6.png)
- 6 -
XS1
RM-Y1010
XS1 SELF DIAGNOSTIC SOFTWARE
The identification of errors within the XS1 chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event
of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flashing
LED) and then communicate with each device in turn to establish if a device is faulty. If a device is found to be faulty the relevant device number
will be displayed through the LED (Series of flashes which must be counted).
Flash Timing Example : e.g. error number 3
StBy LED
ON ON
OFF
OFF
LED Error Code
DEL
RORRE
EDOC
NOITPIRCSEDRORRE
20rorrEc2I
30rorrErednapxEtroP
40rorrEMORPEE
50)3742S8H(rorrEnoitacinummoCihcatiH
60rorrEkcolCemiTlaeR
70rorrEhctiwSVA
80rorrEhctiwSVUY
90rorrEredoceDamorhCniaM
01)9102AXC(redoceDamorhCretliFbmoCD3
11rorrEretliFbmoCD3
21rorrErenuT
31rorrEFI
41rorrEPSM
51)3612AXC(rorrEredocedamorhCbuS
61)0831ADU(noisrevnoCFIDPSoteugolanA
71)9802AXC(rorrEhctiwSVAbuS
81)4114KA(rorrEnoisrevnoCFIDPSotS2I
91)0246AET(rorrEhctiwSoiduA
02)0515PVT(rorrEredoceDamorhCsaxeT
12gninraWerutarepmeThgiH
22rorrEerutarepmeThgiH
32rorrEnoitcetorPnaF
42rorrEnoitcetorPrekaepS
52detcennoctonelnaClenaP2RM
62rorrEeciveDihcatiH
72tsoLnoirartibrACII
82rorrEeciveDAMME
