12
Air Swing
Indoor Temperature Checking Function
This function allows you to shift the air ow direction up and down.
This function allows you to check the current indoor temperature.
Press the Air Swing button to tilt the blade up and down.
Press the Temp. button to check the current indoor temperature.
X
Press the Air Swing button one more time to set the air ow direction,
when the blade reaches the desired position.
The up/down tilting of the blade will stop in place.
X
The current indoor temperature will be displayed.
X
3 seconds after displaying the indoor temperature, the set temperature
will appear.
• With the duct type indoor unit, the air ow direction cannot
be adjusted. If you press the
Air Swing
button,
the
l
amp will appear.
• Indoor unit temperature will be indicated by 0.5 °C(1 °F) units.
• Depending on the installation location of your Wired Remote
Controller, the current indoor temperature can be dierent.
• If the temperature display setting is set to indoor temperature
and you press the Temp. button, then the
lamp
will appear.
