ENGLISH
17
CO2/Power Consumption Check
When the air conditioner is on
Displays the amount of CO2 generated to produce the power required for air conditioner operation and the amount of
power consumption.
Press the [CO
2
/kWh]
button once.
Press the [CO
2
/kWh]
button twice.
[Press the [CO
2
/kWh]
button three times.
The amount of generated
CO
2
is displayed.
The power consumption is
displayed.
The desired temperature is
displayed.
Press the [CO
2/kWh] button once.
Press the [CO2/kWh] button twice.
• If you don't press any button for 10 seconds, the desired
temperature will be displayed.
• If the indoor unit is turned o or the CO
2[kg]/[kWh] display is
not supported, and you have pressed the CO2/[kWh] button,
then the
lamp will appear.
