30
How to Set the Additional User Functions
Current Time Setting (Example)
1. Press the User Set button.
X
(Main Menu) will be displayed, and you can press the [
∧
]/[
∨
] buttons to
select No. 4, which will set the current time.
2. Press the [
＞
] button to select 'Year, Month, Date' in the [Sub-menu].
X
Press the [
∧
]/[
∨
] buttons to select No. 1. You can modify the year/month/
date setting.
3. Press the [
＞
] button to select the 'Year'.
X
Press the [
∧
]/[
∨
] buttons to select the year ('00~'99).
4. Press the [
＞
] button to select the 'Month'.
X
Press the [
∧
]/[
∨
] buttons to select month(01~12).
5. Press the [
＞
] button to select the 'Date'.
X
Press the [
∧
]/[
∨
] buttons to select date(01~31).
6. Press the Set button to complete your setting of 'Year, Month, Date'.
X
The setting changes will be applied and you can exit to the sub-menu.
uhzh~GyGjt~yT~lXWulupiWZ^ZYhTW\UGGGZW YWX\TW[TXWGGG㝘䟸GZaY[aW]
