24
• If you want to cancel your weekly schedules while you are
setting them, then press the Esc button.
• If “Central control” is set, then you can still set a weekly
schedule, but it won’t be actually executed.
11. After pressing the [
＞
] button, select a fan speed.
X
You can only use this for air conditioner on-operation scheduling or when
the operational mode is in Cool/Fan/Heat.
X
Press the
[
∧
]/[
∨
]
buttons repeatedly to toggle the fan speed in order of
(Low )Z(Medium)Z(High)Z(Auto). If Auto operation or Dry operation is
selected, then you can’t set the fan speed.
12.
After pressing the [＞] button, select the ventilator(ERV) related operation mode.
X
You can only use this for Heat-Ex on-operation scheduling.
X
Press the [
∧
]/[
∨
] button, select the ERV related operation mode:
(Heat EX)
Z
(Quiet)
Z
(Away)
Z
(Bypass)
Z
(Auto)
Z
(Purier)
Z
(Heat-Ex / Purier)
Z
(By-Pass / Purier)
Z
(Auto / Purier)
13. After pressing the [
＞
] button, select a fan speed for ventilator(ERV).
X
You can only use this for Heat-Ex on-operation scheduling.
X
Press the [
∧
]/[
∨
] buttons repeatedly to set the fan speed, in order of
(High)
Z
(Turbo)
Z
(Medium).
14. Press the Set button to complete the weekly schedules.
X
'_' is displayed for the selected day, and it will be saved in three seconds.
[e.g. when Monday is reserved ( ) ]
X
If you need to make additional schedules, start again from the weekly and
holiday screen.
15. Press the Esc button to exit to By-Pass mode.
Weekly Schedule Setting
