23
ENGLISH
6. After pressing the [
＞
] button, select the 'Hour.'
X
Press the [
∧
]/[
∨
] button to select the hour setting for the time.
7. After pressing the [
＞
] button, select the 'Minute.'
X
Press the [
∧
]/[
∨
] button to select the minute setting for the time.
8. After pressing the [
＞
] button, select the “On/O” schedule.
X
Press the [
∧
]/[
∨
] buttons repeatedly to select either On or O.
X
If you select ’O’, follow 14¤15.
9.
After pressing the
[
＞
]
button, select the Air Conditioner Related Operation Mode.
X
You can only use this for air conditioner on-operation scheduling.
X
Press the [
∧
]/[
∨
] buttons repeatedly to select from (Auto)Z(Cool)Z
(Dry)Z(Fan)Z(Heat) operation. Depending on the option setting, automatic
or heating operation sometimes cannot be selected.
(When you install the Wired Remote Controller, the setting is available.)
10. Press the [
＞
] button and select the desired temperature.
X
You can only use this for air conditioner on-operation scheduling.
X
Press the [
∧
]/[
∨
] buttons repeatedly to set the temperature by 1 °C(1 °F).
If fan operation is selected, you can’t set the desired temperature.
