28
123 54
SEG Used
6
How to Set the Additional User Functions
1. If you want to set the detailed settings, press the User Set button.
X
You will enter the User Set mode, and the [Main Menu] will be displayed.
2. Refer to the Wired Remote Controller’s User Set list on the next page to select the desired menu.
X
Using the [
∧
]/[
∨
] buttons, select a main menu number and press the [
＞
] button to enter the sub-menu setting
screen.
X
Using the [
∧
]/[
∨
] buttons, select a sub-menu number and press the [
＞
] button to enter the data setting screen.
X
Once you have entered the setting screen, the current setting will be displayed.
X
Refer to the chart for data setting.
X
Using the [
∧
]/[
∨
] buttons, change the settings and press the [
＞
] button to move to the next setting.
X
Press the Set button to save the setting and exit to the sub-menu setting screen.
X
Press the Esc button to exit to general mode.
Main menu Sub-menu
• While setting the data, you can use the
[
＞
]/[
＜
]
buttons to set the range of SEG used.
• While conguring the setting, press the Esc button to exit to the sub-menu setting screen
without saving the setting.
SETTING ADDITIONAL USER FUNCTIONS
