5. Confirmation of parts attached

• This unit includes the following parts. Please check.

• For usage methods, refer to item 10.2.

6. Space required around unit

1 In case of single installation

• Secure enough space around the unit as shown in the figure on page 2.

[Fig. 6.0.1] (P.2)

<A> Top view <B> Side view

<C> When there is little space up to an obstruction

A Front B Unit height

C Back D Air outlet guide (Procured at the site)

(1) If the distance is 300 mm or more between the rear side and the wall

(2) If the distance is 100 mm or more between the rear side and the wall

(3) If the wall height (H) of the front, rear or side exceeds the wall height

restriction

• When the height of the walls on the front, back or on the sides <H> exceeds

the wall height limit as defined here, add the height that exceeds the height

limit <h> to the figures that are marked with an asterisk.

<Wall height limit> Front: Up to the unit height

Back: Up to 500 mm from the unit bottom

Side: Up to the unit height

(4) If there are obstacles at the upper part of the unit

2 In case of collective installation

[Fig. 6.0.2] (P.2)

A Front B Must be open

C Wall height (H)

• When multiple units are installed adjacent to each other, secure enough space

to allow for air circulation and walkway between groups of units as shown in

the figures on page 2.

• At least two sides must be left open.

• As with the single installation, add the height that exceeds the height limit <h>

to the figures that are marked with an asterisk.

• If there is a wall at both the front and the rear of the unit, install up to 6 units

consecutively in the side direction and provide a space of 1000 mm or more as

inlet space/passage space for each 6 units.

7. Lifting method

[Fig. 7.0.1] (P.2)

• Use suspension ropes that will withstand the weight of the unit.

• When moving the unit, use a 4-point suspension, and avoid giving impacts to

the unit (Do not use 2-point suspension).

• Place protective pads on the unit where it comes in contact with the ropes to

protect the unit from being scratched.

• Set the angle of roping at 40° or less.

• Use 2 ropes that are each longer than 8 meters.

• Place protective padding at the corners of the product to protect the product

from scratches or dents that might be caused by the rope.

Caution:

Be very careful when carrying/moving the product.

- When installing the outdoor unit, suspend the unit at the specified location of the

unit base. Stabilize as necessary so that it does not move to the side and support

it at 4 points. If the unit is installed or suspended with 3-point support, the unit

may become unstable and fall.

RP200

RP250

RP300

RP350

1 Connecting elbow

25.4 , OD

25.4

1 pc.

2 Connecting pipe

9.52, OD

12.7

1 pc.

–

3 Connecting pipe

12.7 , OD

15.88

–

1 pc.

7 Connecting pipe

25.4 , OD

34.93

–

1 pc.

4 Connecting pipe

25.4 , OD

19.05

1 pc.

–

RP200

RP250

RP300

RP350

5 Connecting pipe

25.4 , OD

22.2

–

1 pc.

–

6 Connecting pipe

25.4 , OD

28.58

1 pc.

8 Connecting pipe

9.52, OD

9.52

1 pc.

–

9 Connecting pipe

12.7 , OD

12.7

–

1 pc.

Model
