Penetrations

[Fig. 10.4.4] (P.7)

When filling a gap with mortar, cover the penetration part with steel plate so that

the insulation material will not be caved in. For this part, use incombustible mate-

rials for both insulation and covering. (Vinyl covering should not be used.)

• Insulation materials for the pipes to be added on site must meet the following

specifications:

<A> Inner wall (concealed) <B> Outer wall

<C> Outer wall (exposed) <D> Floor (waterproofing)

<E> Roof pipe shaft

<F> Penetrating portion on fire limit and boundary wall

A Sleeve B Heat insulating material

C Lagging D Caulking material

E Band F Waterproofing layer

G Sleeve with edge H Lagging material

I Mortar or other incombustible caulking

J Incombustible heat insulation material

2. Remote control cables

• M-NET Remote Controller

Kind of remote control cable

Cable diameter

Remarks

Sheathed 2-core cable (unshielded) CVV

0.3 to 1.25 mm

(0.75 to 1.25 mm

When 10 m is exceeded, use cable with the

same specifications as 1. Wiring transmission

cables.

Kind of remote control cable

Cable diameter

Remarks

Sheathed 2-core cable (unshielded) CVV

0.3 to 1.25 mm

(0.75 to 1.25 mm

Within 200 m

• MA Remote Controller

* Connected with simple remote controller.

Thickness

Temperature Resistance

Pipe size

ø6.35 to 25.4 mm

10 mm min.

ø28.58 to 41.28 mm

15 mm min.

100°C min.

11. Wiring (For details, refer to the installation manual of each unit and controller.)

* Installation of pipes in a high-temperature high-humidity environment, such as

the top floor of a building, may require the use of insulation materials thicker

than the ones specified in the chart above.

* When certain specifications presented by the client must be met, ensure that

they also meet the specifications on the chart above.

11.1. Caution

1 Follow ordinance of your governmental organization for technical standard re-

lated to electrical equipment, wiring regulations and guidance of each electric

power company.

2 Wiring for control (hereinafter referred to as transmission line) shall be (5 cm

or more) apart from power source wiring so that it is not influenced by electric

noise from power source wiring (Do not insert transmission line and power

source wire in the same conduit).

3 Be sure to provide designated grounding work the to the outdoor unit.

4 Give some allowance to wiring for electrical part box of indoor and outdoor

units, because the box is sometimes removed at the time of service work.

5 Never connect the main power source to terminal block of transmission line. If

connected, electrical parts will burn out.

6 Use 2-core shield cable for transmission line. If transmission lines of different

systems are wired with the same multiplecore cable, the resultant poor trans-

mitting and receiving will cause erroneous operations.

7 Only the transmission line specified should be connected to the terminal block

for outdoor unit transmission.

Erroneous connection does not allow the system to operate.

8 In the case of connecting with an upper class controller or to conduct group

operation in different refrigerant systems, the control line for transmission is

required between the outdoor units in different refrigerant systems.

Connect this control line between the terminal blocks for centralized control

(2-wire line with no polarity).

9 Group is set by operating the remote controller.

11.2. Control box and connecting position of

wiring

1 Outdoor unit

1. Remove the front panel of the control box by removing the 4 screws and push-

ing it up a little before pulling it out.

2. Connect the indoor - outdoor transmission line to the terminal block (TB3) for

the indoor - outdoor transmission line.

If multiple outdoor units are connected in the same refrigerant system, daisy-

chain TB3 (M1, M2,

Terminal) on the outdoor units. Connect the indoor -

outdoor transmission line for the outdoor units to TB3 (M1, M2,

Ter minal) of

only one of the outdoor units.

3. Connect the transmission lines for centralized control (between the centralized

control system and the outdoor unit of different refrigerant systems) to the

terminal block for centralized control (TB7). If the multiple outdoor units are

connected to the same refrigerant system, daisy-chain TB7 (M1, M2, S Termi-

nal) on the outdoor units in the same refrigerant system. (*1)

*1: If TB7 on the outdoor unit in the same refrigerant system is not daisy-

chained, connect the transmission line for centralized control to TB7 on

the OC (*2). If the OC is out of order, or if the centralized control is being

conducted during the power supply shut-off, daisy-chain TB7 on the OC,

OS1, and OS2 (In the case that the outdoor unit whose power supply

connector CN41 on the control board has been replaced with CN40 is out

of order or the power is shut-off, centralized control will not be conducted

even when TB7 is daisy-chained).

*2: OC, OS1, and OS2 of the outdoor units in the same refrigerant system are

automatically identified. They are identified as OC, OS1, and OS2 in de-

scending order of capacity (If the capacity is the same, they will be in

ascending order of their address number).

4. In the case of indoor-outdoor transmission line, connect the shield ground to

the grounding terminal (

). In the case of transmission lines for centralized

control, connect it to the shield terminal (S) on the terminal block for central-

ized control (TB7). Furthermore, in the case of the outdoor units whose power

supply connector CN41 is replaced with CN40, short circuit the shield terminal

(S) and the grounding terminal (

) in addition to the above.

5. Fix the connected wires securely in place with the cable strap at the bottom of

the terminal block. External force applied to the terminal block may damage it

resulting in a short circuit, ground fault, or a fire.

[Fig. 11.2.1] (P.8)

A Power source B Transmission line

C Earth screw

[Fig. 11.2.2] (P.8)

A Cable strap B Power source line

C Transmission line

2 Conduit tube installation

• Open by hammering the knockout holes for the conduit tube located on the

base and the bottom part of the front panel.

• When installing the conduit tube directly through the knockout holes, remove

the burr and protect the tube with masking tape.

• Use the conduit tube to narrow down the opening if there is a possibility of

small animals entering the unit.

11.3. Wiring transmission cables

1 Types of control cables

1. Wiring transmission cables

•Types of transmission cables: Shielding wire CVVS, CPEVS or MVVS

• Cable diameter: More than 1.25 mm

• Maximum wiring length: Within 200 m

• Maximum length of transmission lines for centralized control and indoor/out-

door transmission lines (Maximum length via outdoor units): 500 m MAX

The maximum length of the wiring between power supply unit for transmission

lines (on the transmission lines for centralized control) and each outdoor unit

and system controller is 200 m.

WT05910X01_en_e.p65 10.5.18, 15:4518
