GENERAL
Carefully read the contents of this leaflet since it provides
important instructions regarding safety of installation, use and
maintenance. Keep the leaflet for possible future consultation.
All the operations relating to installation/replacement
(electrical connections) must be carried out by specialised
personnel in conformity with the regulations in force.
SAFETY PRECAUTION
It is recommended to use flat-bottom pans with a diameter
equal to or slightly larger than that of the heated area. Do not
use pans with a rough base to prevent scratching the heat
surface of the cooktop (Fig.2). This appliance is not suitable
for use by children or persons requiring supervision. Do not
let children play with the appliance.
Before connecting the appliance to the electricity sup-
ply:
- Check that the voltage and power values listed on the data
plate (positioned on the lower part of the appliance) are com-
patible with the electricity supply and socket. If you have any
doubts, please consult a quali ed electrician for assistance.
Important
- Avoid spilling liquid, therefore to boil or heat liquids, reduce
the heat.
- Do not leave the heating elements on with empty pots and
pans or without receptacles.
- When you have finished cooking, switch off the relevant
heating element with the control indicated below.
Attention:
- Steam cleaners must not be used.
- If the surface is cracked, switch o the appliance to
prevent electric shock.
- This appliance is not intended for use by young children
or in rm persons without supervision
- Young children should be supervised to ensure they do
not play with the appliance
This appliance conforms to the European Directive EC/2002/96,
Waste Electrical and Electronic Equipment (WEEE). By making
sure that this appliance is disposed of in a suitable manner,
the user is helping to prevent potential damage to the
environment or to public health.
The
symbol on the product or on the accompanying
paperwork indicates that the appliance should not be treated
as domestic waste, but should be delivered to a suitable
electric and electronic appliance recycling collection point.
Follow local guidelines when disposing of waste. For more
information on the treatment, re-use and recycling of this
product, please contact your local authority, domestic waste
collection service or the shop where the appliance was
purchased.
INSTALLATION INSTRUCTIONS
These instructions address specialised installers and serve
as a guide for installation, adjustment and maintenance in
conformity with the laws and regulations in force.
If a built-in oven or any other appliance that generates heat
must be fitted directly under the glass-ceramic cooktop,
THIS APPLIANCE (oven) AND THE GLASS-CERAMIC COOKTOP
MUST BE SUITABLY INSULATED in such a way that the heat
generated by the oven, measured on the bottom right of
the cooktop, does not exceed 60°C. Failure to respect this
precaution may determine improper functioning of the
TOUCHCONTROL system.
Positioning (Fig.1)
The domestic appliance is designed to be built into a worktop
as illustrated in the specific figure. Apply sealant around the
entire perimeter (cut-out dimensions Fig.1B).
Fix the domestic appliance on the worktop by means of the
4 brackets provided, taking the thickness of the worktop
into account (Fig.1A). If the lower part of the appliance, after
installation, is accessible via the lower part of the cabinet
then it is necessary to mount a separator panel respecting the
distances indicated (Fig.1C). If the appliance is installed with
an oven underneath then the separator is not necessary.
Electrical connections
before making the electrical connections, check that:
- the ground cable is 2 cm longer than the other cables;
- the system ratings meet the ratings indicated on the
identi cation plate xed on the lower part of the worktop;
- the system is tted with e cient earthing compliant to
the laws and regulations in force.
Earthing is obligatory by law.
If the appliance is not tted with a cable, use type:
“H05V2V2-F” for a power level of up to 6400 Watts. The cross-
section of the cable should be at least 2.5 mm, or 4 mm for
greater power levels.
The cable should never reach a temperature which is 50°C
above the temperature of the room in which it is installed.
The appliance is designed for permanent connection to the
electricity supply and should therefore be fitted with an
omnipolar switch which has a minimum opening of 3 mm
between contacts. The switch should be suitable for the char-
ge indicated on the appliance data plate and must conform to
all current legislation (the yellow/green earth wire must not
be interrupted by the switch).
The omnipolar switch must be easy to reach once the instal-
lation process has been completed.
USE AND MAINTENANCE
Maintenance
Remove any residues of food and drops of grease from
the cooking surface using the special scraper supplied on
request (Fig.3)
Clean the heated area as thoroughly as possible using SIDOL,
STAHLFIX or similar products and a cloth/paper, then rinse
with water and dry with a clean cloth.
Using the special scraper (optional) immediately remove
any fragments of aluminium and plastic material that have
unintentionally melted on the heated cooking area or residues
of sugar or food with a high sugar content (Fig.3). In this way,
any damage to the cooktop surface is prevented.
ENGLISH
GB
- 17 -
