Peg-Perego RAIDER POLICE (ED0910) [9/40] Assembly instructions

For the safety of the child, before starting up the

vehicle read and carefully follow the following

instructions.

• Teach the child how to use the vehicle properly for

safe and enjoyable driving.

• Before starting, check that there are no people or

objects obstructing the vehicle’s path.

• Drive with hands on the handlebars/steering wheel

and always watch the road ahead.

• Brake in good time to avoid collisions.

2nd GEAR (if present)

Initially, use in 1st gear is recommended. Before

enabling 2nd gear, check that the child has learned to

use the handlebars/steering wheel, 1st gear and the

brake correctly, and has become familiar with the

vehicle.

WARNING!

• Check that all the wheel fixing studs/nuts are

fastened properly.

• If the vehicle is overloaded, as can happen on soft

sand, mud, or very uneven ground, the overload

switch will immediately disconnect the power. The

power supply will be restored after a few seconds.

• Only for 12 and 24 Volt vehicles: in first gear the

vehicle has a differential effect like a real motor

vehicle; on smooth terrain and with just one child

on board, the two wheels can turn at different

speeds and they can slip and slow down.

UNINTERRUPTED FUN: Keep a spare set of charged

batteries ready for use.

THE VEHICLE DOES NOT WORK?

• Check that there are no disconnected cables under

the accelerator plate.

• Check the operation of the accelerator button and

replace it if necessary.

• Check that the battery is connected to the

electrical system.

THE VEHICLE LACKS POWER?

• Charge the batteries. If after charging the problem

persists, have the battery and charger checked by

an assistance centre.

PROBLEMS?

RULES FOR SAFE DRIVING

PEG PEREGO offers an after-sales assistance service,

directly or through a network of authorized

assistance centres, for any repairs or replacements

and the sale of original spare parts. To contact the

assistance centres refer to the “Assistance Centres”

booklet included in the packaging.

Peg Perego always strive to best satisfy their

customers' needs. Knowing the opinions of our

customers is therefore very important and valuable

to us. We would be very grateful if, once you have

used the product, you would fill out the CONSUMER

SATISFACTION QUESTIONNAIRE

which you can find on

the internet at: www.pegperego.com, making

any observations or suggestions you might have.

ASSISTANCE SERVICE

WARNING

ASSEMBLY MUST ONLY BE CARRIED OUT BY

ADULTS. TAKE CARE WHEN REMOVING THE

VEHICLE FROM ITS PACKAGING. ALL THE

SCREWS AND SMALL PARTS ARE CONTAINED IN

A BAG INSIDE THE PACKAGING. THE BATTERY

MAY ALREADY BE FITTED INSIDE THE ITEM.

ASSEMBLY

1 • Clip the rear mudguard into place by inserting

the 3 tabs in the slots in the bodywork shown by

the arrows.

2 • Turn the body work upside down and attach the

mudguard to it by pressing it, making sure the

centre tab is inserted first (A).

• Repeat steps 1 and 2 on the other side.

3 • Insert the handle in the hole in the bodywork (1)

and turn it downwards (2). PLEASE NOTE: The

two handles are different. Position them with the

flat side facing the saddle.

4 • Turn the bodywork over to access the underside

and attach the handle with the screw provided.

• Repeat steps 3 and 4 with the other handle.

5 • Place bushing A on one of the two wheels with

only one hubcap, lining the 4 pins up with the

holes.

6 • Insert the long metal axle into the wheel.

7 • Slide a washer onto the axle.

8 • Insert the axle with the wheel and washer in the

hole on the right hand side of the bodywork, as

shown in the figure.

9 • Place the remaining bushing (B) on the other

wheel with only one hubcap.

10 •Insert the wheel on the axle on the left hand

side of the bodywork, making sure the wheel

bushing is properly fitted into the pentagon on

the trike.

11 •Place the red tool on one of the two ends of the

axle.

12 •Turn over the bodywork, keeping the red tool

underneath.

13 •Insert a stud in the black tool.

14 •Put it on the other end of the axle as shown in

the figure and use a hammer to secure the wheel

with the stud.

• Turn the trike over and repeat the procedure to

secure the other wheel.

15 •Look closely at the handlebar tubes to ensure

they are fitted properly. The left hand tube

(marked SX) has two holes in the upper section,

unlike the right hand one (marked DX).

16 •Insert the right tube in the right hand side of the

front section, as shown in the figure.

17 •Secure it with the screw provided.

• Repeat steps 16 and 17 with the left tube.

18 •Insert the front mudguard onto the handlebar

tubes, positioning it as shown in the figure.

PLEASE NOTE: The mudguard is fitted with two

tabs that prevent it from being fully attached if it

is inserted incorrectly.

19 •Insert the caps in the handlebar tubes,

positioning them as shown in figure A.

20 •Insert the wheel between the tubes and line up

all the holes. Insert the short metal axle.

21 •Put the red tool in place and turn over the entire

handlebar unit, keeping the red tool underneath.

• Insert a stud in the black tool and secure the

wheel as shown in the figure.

• Turn the handlebar unit onto the other side and

repeat the procedure to secure the wheel there

too.

22 •Attach the nut provided under the front section.

23 •Attach the handlebar unit to the bodywork,

ensuring that the clip locks into place in the part

below the front section (see the details in the

following picture).

24 •The clip has to lock into the curved slot, as

shown in detail in the figure (A: view from above

- B: view from below).

25 •Attach the tank cover by clipping into place the 3

tabs in the bodywork, as shown in the figure.

26 •Insert the threaded pin.

27 •Fasten the threaded pin to attach the handlebar

unit to the bodywork, holding the nut under the

front section still with the other hand.

28 •Insert the hand guard marked DX on the right

handlebar tube and the hand guard marked SX

on the left handlebar tube. The picture shows

how to fit the hand guard marked SX.

29 •Secure the hand guards with the screws

provided.

30 •Wet the inside of the rubber grip to make it

easier to slide onto the handlebar tube. The

rubber grips are identical and can go on the right

or left side.

31 •ONLY FOR THE MODELS IGED0910

ASSEMBLY INSTRUCTIONS

POLICE/POLIZEI and IGED0912 PRINCESS:

Attach the silver sticker included in the packet.

32 •Clip the headlight into place, pressing first on

the upper part and then on the lower part.

33 •Insert the windshield into the upper part of the

front section.

34 •Press the windshield against the front section in

the points shown in the figure.

35 •Attach the windshield with the two screws

provided.

36 •Connect the electrical system plug to the

battery.

37 •Insert the front part of the saddle in the

bodywork (1), then pull it down (2).

38 •Push the locking clip all the way down in the

hole at the rear of the saddle.

39 •Turn the locking clip to position B to secure the

saddle.

FEATURES AND USE OF THE VEHICLE

40 •The vehicle is ready for use. With both hands on

the handlebar, press the accelerator pedal with

your foot.

REPLACING THE BATTERY

41 •Turn the locking clip to position A to release the

saddle. Remove the saddle.

42 •Disconnect the electrical system plug from the

battery.

43 •Unfasten the screw on the battery holder.

Remove the battery holder.

44 •Replace the flat battery with another battery

that has been charged for at least 14 hours.

PLEASE NOTE: Replacement batteries are only

sold with electrical power of 6V/8Ah. This does

not affect the operation of the vehicle.

45 •Replace the battery holder and secure it with

the screw. Reconnect the plugs. Replace the

saddle and turn the locking clip to position B.

• WARNING: After working inside the battery

compartment, always remember to secure the

components with the screw and clip.

CHARGING THE BATTERY

WARNING: BATTERY CHARGING AND ANY

OTHER WORK ON THE ELECTRICAL SYSTEM

MUST BE CARRIED OUT BY ADULTS.

THE BATTERY CAN ALSO BE CHARGED

WITHOUT REMOVING IT FROM THE TOY.

46 •Disconnect plug A of the electrical system from

the battery plug B by pressing the sides.

47 •Plug the battery charger into a domestic power

supply, following the instructions provided with

it. Connect plug B to the battery charger plug C.

• When charging is complete, unplug the battery

charger from the domestic socket and then

disconnect plug C from plug B.

48 •Push plug B into plug A until it clicks into place.

After completing the procedure, always

remember to replace and secure the saddle.

Peg-Perego RAIDER POLICE (ED0910) [9/40] Assembly instructions
