GRAPHITE 58G970 [12/84] Technical parameters

● Cleaning the device after each use is recommended.

Do not use water or any other liquid for cleaning. ●

Clean the reciprocating saw with a dry cloth or blow with compressed air at low pressure. Do not use ●

any cleaning agents or solvents, they may damage plastic parts.

Clean ventilation holes in the motor casing regularly to prevent device overheating. ●

In case of excessive commutator sparking, have the technical condition of carbon brushes of the motor ●

checked by a qualied person.

Store the reciprocating saw in a dry place, beyond reach of children. ●

REPLACEMENT OF CARBON BRUSHES

Replace immediately worn out (shorter than 5 mm), burnt or cracked motor carbon brushes. Always replace

both brushes at a time.

Unscrew and remove carbon brush covers ( ● 3).

Remove worn out carbon brushes ● .

Remove any carbon dust with compressed air. ●

Insert new carbon brushes. Brushes should easily move into brush-holders. ●

Fix carbon brush covers ( ● 3).

After the brushes are replaced start the mitre saw with no load and wait until the brushes t to the

motor commutator. Entrust replacement of carbon brushes only to a qualied person. Only original

parts should be used.

All faults should be repaired by service workshop authorized by the manufacturer.

TECHNICAL PARAMETERS

RATED PARAMETERS

Reciprocating Saw

Parameter Value

Supply voltage 230 V AC

Input current frequency 50 Hz

Rated power 1100 W

Blade stroke cycles (without load) 0 – 2500 spm

Maximum thickness of cut material

Wood 180 mm

Steel 20 mm

Blade stroke length 29 mm

Protection class II

Weight 3,9 kg

Year of production 2014

NOISE LEVEL AND VIBRATION PARAMETERS

Sound pressure: Lp

= 89,7 dB(A) K = 3 dB(A)

Sound power: Lw

= 100,7 dB(A) K = 3 dB(A)

Vibration acceleration: a

= 12,576 m/s

K = 1,5 m/s

ENVIRONMENT PROTECTION

Do not dispose of electrically powered products with household wastes, they should be utilized in

proper plants. Obtain information on wastes utilization from your seller or local authorities. Used up

electric and electronic equipment contains substances active in natural environment. Unrecycled

equipment constitutes a potential risk for environment and human health.

* Right to introduce changes is reserved.
