Zelmer Wodnik Trio 619.5 EW [123/128] Cleaning smooth floors

123

In case of steam cleaning use only the equipment listed below:the detergent/

steam hose, the detergent/steam extension pipes, a big spray nozzle,

a suction nozzle, a brush and a connector.

The suction nozzle – is used to collect water from ﬂ oor

coverings, carpets and ﬂ oors.

The brush – together with the connector and the suction

nozzle, facilitates cleaning tile joints, crevices, upholstery on

armchairs and seats, etc.

The steam spray nozzle – is used to wash carpets, to clean smooth areas, walls,

tiles and to collect water from them.

The cleaning insert – is ﬁ xed to the steam spray nozzle.It facilitates cleaning and

scrubbing smooth surfaces, walls and coverings.

The collecting insert – is ﬁ xed to the steam spray nozzle.It facilitates cleaning

windows, smooth surfaces, walls, tiles in bathrooms and to collect water from

ﬂ oors.

Press the button on the hose grip to adjust the water –

inﬂ ow to the nozzle.

ATTENTION! In case of the spray nozzle gets

clogged disconnect the nozzle from

the extension tube and clean (blow

through) the duct or replace the nozzle

jet. A complete set of spare jets is

provided.

CLEANING SMOOTH FLOORS

Place the collecting insert in the nozzle. –

Set the three-position switch ( – 1) to “2” and turn the vacuum cleaner on (as in

case of deep cleaning the carpets).

Replacement of jets

1. Remove the jet with a ø 5.6x1 rubber ring from the big spray nozzle, press the jet downwards with your

thumb as indicated on the nozzle.

2. Wet a new jet and a rubber ring and press it into the slot in the nozzle until you hear a click.

Move the nozzle on the cleaned area back and forth. –

Upon cleaning a part of the ﬂ oor, stop spraying (set the three-position switch ( – 1) from “2” to “0”) and

suck the liquid in through moving the nozzle slowly towards you until the cleaning solution is removed

from the ﬂ oor.

Repeat this operation until the entire ﬂ oor is cleaned and dries up. –

Once you have completed spraying turn off the pump (set the three-position switch ( – 1) from “2” to “0”)

and press the button on the hose grip to adjust the water ﬂ ow to the nozzle to “release the pressure”.

ATTENTION! If you performed a wet cleaning (removing wet contamination), just before ﬁ nishing

your work suck in about 1-2 litres of pure water to rinse the hose and the extensions

tubes and then suck in the air to dry them.

STEAM CLEANING – Accessories for steam cleaning

Work in a steam cleaning mode

Prior to steam cleaning check (in a place which is not visible well) if the material to be cleaned is resistant

to temperature, e.g.:

leather or lacquered wood may fade out, –

unprotected wood may swell, –

protective wax layers may peel off, –

plastics may suffer from deformation, –

plastic cloths, velvet, acryl may be damaged. –

instrukcja 616-010.indb 123instrukcja 616-010.indb 123 2010-02-23 10:19:022010-02-23 10:19:02

Zelmer Wodnik Trio 619.5 EW [123/128] Cleaning smooth floors
