Code Alarm Description Comp. #1 Comp. #2 Pump Evap. Pump Cond.
Status Status Status Status
AL01
Wrong power
Off Off Off Off
AL02
Antifreeze alarm
Off Off On Off
AL03
Interlock
Off Off Off Off
AL04
Flow switch alarm
Off Off Off Off
AL05
System #1 low suction pressure
OffOnOnOn
AL06
System #2 low suction pressure
On Off On On
AL07
System #1 high discharge pressure
Off On On On
AL08
System #2 high discharge pressure
On Off On On
AL09
Compressor #1 thermal protection
Off On On On
AL10
Compressor #2 thermal protection
On Off On On
AL14 Remote interlock n°1 Off On On On
AL15 Remote interlock n°2 On Off On On
AL18
Clock board failure
On On On On
AL21 B1 wrong signal Off Off On Off
AL22
B2-LP1 sensor failure
Off On On On
AL23
B3-DP1 sensor failure
On On On On
AL24
B4-TEin sensor failure
On On On On
AL25
B5-TEout sensor failure
Off Off On On
AL26
B6-LP2 sensor failure
On Off On On
AL27
B7-DP2 sensor failure
On On On On
AL28
B8-Tplan sensor failure
Off Off On On
AL29
B9-TCin sensor failure
On On On On
AL30 B10-TCout sensor failure On On On On
AL31
SYS #1 compressor
Maintenance
On On On On
AL32
SYS #2 compressor
Maintenance
On On On On
AL33
Pump maintenance
On On On On
AL37
System #1 compressor
differential pressure
Off On On On
AL38
System #2 compressor
differential pressure
On Off On On
Notes:
1 = Check power phases rotation and/or minimum voltage. It works only in case the Phases Monitor (accessory) is installed.
6.3 Functions / Keys / Configuration
I
Alarms Table
I
“Menu” key
Pushing the “Menu” key the main mask is displayed:
U:1 RWT ................... 0.0 °C
SYS#1: OFF
SYS#2: OFF
Unit ON
In this mask the following items are displayed:
– unit serial number and control temperature
– system #1 status
– system #2 status
– unit status.
