Page 34
Technical data
SWS 1602-2352 R134a
SWS R134a 1602 1902 2202 2212 2352
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Charge (1) kg 46 61 74 52 55
Compressors
Type Screw
Number 22222
TStart-up type P/W Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 13.0 17.3 21.0 25.3 27.0
Pressure drop kPa 44.4 54.4 53.7 42.2 40.5
Water content l 80.2 124.7 221.7 162.0 184.0
Condenser
Type Shell & Tube
Number 22222
Water flow rate l/s 8.0 10.5 12.7 15.3 16.4
Pressure drop kPa 28.7 38.7 41.0 40.1 45.7
Water content l 30.8 49.4 55.4 62.0 62.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 5" 6" 8" 6" 6"
Outlet diameter inch 5" 6" 8" 6" 6"
Hydraulic connections Condenser
Type Gas threaded female
Inlet diameter inch 2"
1
/
2
3" 3" 3" 3"
Outlet diameter inch 2"
1
/
2
3" 3" 3" 3"
Weights
Shipping kg 2067 2554 3005 3377 3470
Operating kg 2144 2688 3212 3601 3717
Dimensions
Length mm 3795 3795 4210 4210 4210
Width mm 950 950 1400 1400 1400
Height mm 1910 1910 2050 2050 2050
(1) Indicative value. Always refer to the value specified on the unit’s label.
Manuale SWS-SWR EN1.qxp 05/11/06 14:19 Pagina 34
