Page 40
Technical data
SWR 2502-3202 R134a
SWR R134a 2502 2652 2802 3012 3202
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Compressors
Type Screw
Number 22222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 28.7 30.5 32.4 34.2 37.5
Pressure drop kPa 45.7 56.3 63.4 70.6 52.8
Water content l 184.0 222.0 222.0 222.0 359.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 6” 6” 6” 6” 8”
Outlet diameter inch 6” 6” 6” 6” 8”
Weights
Shipping kg 2995 3085 3095 3505 4421
Operating kg 3179 3307 3317 3727 4780
Dimensions
Length mm 4210 4210 4210 4210 4670
Width mm 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2050 2050
