Page 36
Technical data
SWS R134a 3412 3602 4212 4602 4802
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Charge (1) kg 82 88 94 102 110
Compressors
Type Screw
Number 22222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 40.2 42.9 46.0 49.7 53.4
Pressure drop kPa 60.8 65.7 75.3 88.0 101.7
Water content l 359.0 359.0 359.0 399.0 399.0
Condenser
Type Shell & Tube
Number 22222
Water flow rate l/s 24.4 26.0 28.2 30.4 32.5
Pressure drop kPa 29.0 33.0 38.7 41.7 47.9
Water content l 126.0 126.0 126.0 133.0 133.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 8” 8” 8” 8” 8”
Outlet diameter inch 8” 8” 8” 8” 8”
Hydraulic Connections Condenser
Type Victaulic
Inlet diameter inch 4” 4” 4” 4” 4”
Outlet diameter inch 4” 4” 4” 4” 4”
Weights
Shipping kg 4970 4986 5112 5165 5342
Operating kg 5455 5471 5597 5698 5875
Dimensions
Length mm 4670 4670 4670 4670 4670
Width mm 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2110 2110
SWS 3412-4802 R134a
(1) Indicative value. Always refer to the value specified on the unit’s label.
Manuale SWS-SWR EN1.qxp 05/11/06 14:19 Pagina 36
