Technical data
SWR R407C 1002 1202 1402 1602 1902 2202
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 222222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R407C
Compressors
Type Screw
Number 222222
Start-up type Part-Winding Y/∆
Evaporator
Type Shell & Tube
Number 111111
Water flow rate L/s 13.9 14.9 16.6 18.8 23.4 28.6
Pressure drop kPa 45.4 52.5 31.1 40.0 42.7 37.5
Water content l 93.3 93.3 80.2 80.2 124.7 221.7
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 5" 5" 5" 5" 6" 8"
Outlet diameter inch 5" 5" 5" 5" 6" 8"
Refrigerant connections
Type To be welded
Discharge diameter inch 1”
5
/8 1”
5
/8 1”
5
/8 1”
5
/8 2”
1
/8 2”
1
/8
Liquid diameter inch 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8
Weights
Shipping kg 1370 1380 1755 1765 2065 2453
Operating kg 1463 1473 1835 1845 2190 2675
Dimensions
Length mm 3795 3795 3795 3795 3795 4210
Width mm 950 950 950 950 950 1400
Height mm 1910 1910 1910 1910 1910 2050
SWR 1002-2202 R407C
