Page 41
Technical data
English
SWR 3412-4802 R134a
SWR R134a 3412 3602 4212 4602 4802
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Compressors
Type Screw
Number 22222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 40.2 42.9 46.0 49.7 53.4
Pressure drop kPa 60.8 65.7 75.3 88.0 101.7
Water content l 359.0 359.0 359.0 399.0 399.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 8” 8” 8” 8” 8”
Outlet diameter inch 8” 8” 8” 8” 8”
Weights
Shipping kg 4431 4441 4561 4581 4753
Operating kg 4790 4800 4920 4980 5153
Dimensions
Length mm 4670 4670 4670 4670 4670
Width mm 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2010 2010
Manuale SWS-SWR EN1.qxp 05/11/06 14:19 Pagina 41
