8.2 Technical data
SWS 1002-2202 R407C
(1) Indicative value. Always refer to the value specified on the unit’s label.
SWS R407C 1002 1202 1402 1602 1902 2202
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 222222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R407C
Charge (1) kg 59 63 70 80 99 122
Compressors
Type Screw
Number 222222
Start-up type Part-Winding Y/∆
Evaporator
Type Shell & Tube
Number 111111
Water flow rate l/s 13.9 14.9 16.6 18.8 23.4 28.6
Pressure drop kPa 45.4 52.5 31.1 40.0 42.7 37.5
Water content l 93.3 93.3 80.2 80.2 124.7 221.7
Condenser
Type Shell & Tube
Number 222222
Water flow rate l/s 8.9 9.6 10.6 12.1 14.9 18.2
Pressure drop kPa 44.0 50.9 59.8 62.8 72.2 54.5
Water content l 28.4 28.4 28.4 30.8 49.4 62.4
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 5" 5" 5" 5" 6" 8"
Outlet diameter inch 5" 5" 5" 5" 6" 8"
Hydraulic connections Condenser
Type Gas threaded female
Inlet diameter inch 2"
1
/
2
2"
1
/
2
2"
1
/
2
2"
1
/
2
3" 3"
Outlet diameter inch 2"
1
/
2
2"
1
/
2
2"
1
/
2
2"
1
/
2
3" 3"
Weights
Shipping kg 1645 1659 2041 2067 2554 3005
Operating kg 1768 1780 2148 2176 2728 3288
Dimensions
Length mm 3795 3795 3795 3795 3795 4210
Width mm 950 950 950 950 950 1400
Height mm 1910 1910 1910 1910 1910 2050
