Page 33
English
Technical data
(1) Indicative value. Always refer to the value specified on the unit’s label.
SWS R407C 2602 3002 3402 3802 4202 4402
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 222222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R407C
Charge (1) kg 142 160 181 209 219 233
Compressors
Type Screw
Number 222222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 111111
Water flow rate l/s 33.5 37.7 42.5 49.1 51.5 54.8
Pressure drop kPa 51.3 53.0 63.4 86.5 95.1 107.7
Water content l 221.7 206.5 184.4 222.2 222.2 222.2
Condenser
Type Shell & Tube
Number 222222
Water flow rate l/s 21.2 23.9 26.9 31.1 32.7 35.1
Pressure drop kPa 53.1 67.4 80.9 64.9 68.3 78.5
Water content l 71.4 71.4 71.4 95.0 95.0 95.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 8" 8" 8" 8" 8" 8"
Outlet diameter inch 8" 8" 8" 8" 8" 8"
Hydraulic connections Condenser
Type Gas threaded female
Inlet diameter inch 3 3 3 4” 4” 4"
Outlet diameter inch 3 3 3 4” 4” 4"
Weights
Shipping kg 3259 3326 3460 4330 4380 4254
Operating kg 3552 3604 3716 4648 4696 4572
Dimensionss
Length mm 4210 4210 4210 4210 4210 4210
Width mm 1400 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2050 2050 2050
SWS 2602-4402 R407C
Manuale SWS-SWR EN1.qxp 05/11/06 14:19 Pagina 33
