Page 38
Technical data
SWR R407C 2602 3002 3402 3802 4202 4402
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 222222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R407C
Compressors
Type Screw
Number 222222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 111111
Water flow rate l/s 33.5 37.7 42.5 49.1 51.5 54.8
Pressure drop kPa 51.3 53.0 63.4 86.5 95.1 107.7
Water content l 221.7 206.5 184.4 222.2 222.2 222.2
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 8" 8" 8" 8" 8" 8"
Outlet diameter inch 8" 8" 8" 8" 8" 8"
Refrigerant connections
Type To be welded
Discharge diameter inch 2”
5
/8 2”
5
/8 2”
5
/8 3”
1
/8 3”
1
/8 3”
1
/8
Liquid diameter inch 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8 1”
3
/8
Weights
Shipping kg 2663 2712 2825 3495 3535 3395
Operating kg 2885 2919 3009 3717 3757 3617
Dimensions
Length mm 4210 4210 4210 4210 4210 4210
Width mm 1400 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2050 2050 2050
SWR 2602-4402 R407C
