SSppaarree ppaarrttss
11 SPARE PARTS
11.1 Spare part list
The table below shows the list of spare parts recom-
mended during the first two years of operation.
CCoommppoonneenntt NNuummbbeerr
HP pressure switch 1
Gas filter 2
Thermostatic valve 2
Auxiliary relays 2
Compressor’s fuses 6
Auxiliary fuses 6
Set of compressor contactors 1
Water sensor 1
High Pressure Transductor 1
Low Pressure Transductor 1
Electronic card 1
Keyboard 1
Compressor oil resistor 1
11.2 Oil for compressors
The compressors are lubricated with:
11.3 Wiring diagrams
The wiring diagrams are installed inside the doors of
the electrical panels of the unit.
Any request for wiring diagrams shall be forwarded
to Itelco-Industry Service Centre.
DEA SE 170
CPI CP- 4214-320
Compressor Refrigerant Lubricant oil
REFCOMP
BITZER
R134a, R407C
R22
R134a, R407C
R22
BITZER BSE 170
BITZER B320SH
