Technical data
(1) Indicative value. Always refer to the value specified on the unit’s label.
SWS 2502-3202 R134a
SWS R134a 2502 2652 2802 3012 3202
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Charge (1) kg 59 63 66 70 77
Compressors
Type Screw
Number 22222
Start-up type Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 28.7 30.5 32.4 34.2 37.5
Pressure drop kPa 45.7 56.3 63.4 70.6 52.8
Water content l 184.0 222.0 222.0 222.0 359.0
Condenser
Type Shell & Tube
Number 22222
Water flow rate l/s 17.4 18.5 19.6 20.8 22.8
Pressure drop kPa 41.6 47.0 50.2 50.5 60.5
Water content l 68.0 68.0 68.0 71.0 71.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 6" 6" 6" 6" 8"
Outlet diameter inch 6" 6" 6" 6” 8"
Hydraulic connections Condenser
Type Gas threaded female
Inlet diameter inch 3" 3" 3" 3" 3"
Outlet diameter inch 3" 3" 3" 3" 3"
Weights
Shipping kg 3498 3592 3605 4029 4952
Operating kg 3750 3882 3895 4323 5382
Dimensions
Length mm 4210 4210 4210 4210 4670
Width mm 1400 1400 1400 1400 1400
Height mm 2050 2050 2050 2050 2050
