Page 39
English
Technical data
SWR 1602-2352 R134a
SWR R134a 1602 1902 2202 2212 2352
Nominal voltage V/ph/Hz 400/3/50
Number of circuits 22222
Number of steps 6
Capacity steps % 25/50/63/75/87/100
Refrigerant
Type R134a
Compressors
Type Screw
Number 22222
Start-up type P/W Y/∆
Evaporator
Type Shell & Tube
Number 11111
Water flow rate l/s 13.0 17.3 21.0 25.3 27.0
Pressure drop kPa 44.4 54.4 53.7 42.2 40.5
Water content l 80.2 124.7 221.7 162.0 184.0
Hydraulic connections Evaporator
Type Victaulic
Inlet diameter inch 5" 6” 8” 6” 6”
Outlet diameter inch 5" 6” 8” 6” 6”
Weights
Shipping kg 1765 2065 2453 2895 2985
Operating kg 1845 2190 2675 3057 3169
Dimensions
Length mm 3795 3795 4210 4210 4210
Width mm 950 950 1400 1400 1400
Height mm 1910 1910 2050 2050 2050
