28 RECORDING
16 If you make a mistake, go back with t (left cursor) and
re-enter the information.
17 Confirm with ENTER/OK.
➤ When all information is correct, the data is stored
in a timer block.
18 To end, press TIMER.
19 Make sure you inserted a disc without write protec-
tion. If you inserted a write protected disc, recording
will not occur.
20 Turn the Recorder to standby mode by pressing
POWER (B/I).
If a timer recording is incorrect
The following messages may appear in the timer menu
when you set a timer recording:
Collision
The Timer recording overlaps with another timer
recording.
Solution:
● Ignore by pressing TIMER again. The program with
the earlier start time will record completely. Then
the remainder of the later program will record.
● Edit one or both timer recordings.
● Delete one of the timer recordings.
Please enter channel number
The VCR Plus+ system does not recognize the TV channel.
Solution:
● Select the required channel number with t/u (left/
right cursor).
● Press ENTER/OK to confirm.
PlusCode number wrong
You entered an incorrect PlusCode number.
Solution:
● Enter the correct information or quit by pressing
TIMER.
Weekend programming - not possible
Date was incorrectly entered. Daily programming can only
be used for recordings from Mondays to Fridays.
Memory full
All the timer blocks are in use.
Solution:
● Delete one of the Timer recordings.
Clock not set-check Clock channel
The clock is not set. Set it manually (See ‘Time/Date
Manually’) or adjust the Clock channel (See ‘Time/Date
Automatic.’)
Data error
Solution:
● Make sure all information is correct and complete.
Checking or altering a Timer Recording
1 Press TIMER on the remote control.
2 Select ‘Timer list’ with w/v (down/up cursor).
3 Press u (right cursor).
4 Select the timer recording you want to check or alter
with w/v (down/up cursor).
➤ The selected timer recording will be highlighted in
blue.
5 Press u (right cursor).
6 Select what you want to check or alter with t/u (left/
right cursor).
7 Alter data with w/v (down/up cursor) or with the
digit buttons 0-9.
8 Press ENTER/OK to conform.
9 To end, press TIMER, repeatedly if necessary to
remove the menus.
10 Turn the Recorder to standby mode by pressing
POWER (B/I).
Timer
To exit
Press TIMER
Timer programming
Timer list
VCR Plus system
+
Timer
Timer List
Date
04 / 20
07 / 20
10 / 20
11 / 20
120
089
065
120
09 : 00 P M
08: 30 P M
07: 00 A M
09: 00 P M
11: 00 P M
09: 30 P M
07: 30 A M
11: 00 P M
SP
SP
SP
SP
Ch. Start End
Rec
Mode
Total record time 05: 30
To exit
Press TIMER
To change
Press >
+
+
+
+
