34 PLAYBACK
Zoom
The Zoom function allows you to enlarge the video image
and pan through the enlarged image.
1 Press ZOOM.
➤ The system menu bar appears with Zoom selected.
2 Press w/v (down/up cursor) to activate the Zoom
function and select the required zoom factor; 1.33, 2
or 4.
➤ Playback will pause.
➤ The picture will change accordingly.
➤ The selected zoom factor appears below the Zoom
icon in the system menu bar. ‘Press OK to pan’
appears below the system menu bar.
3 Press ENTER/OK.
➤ The panning icons w/v/u/t (down/up/right/left
cursor) and ENTER/OK appear on the screen.
4 Use w/v/u/t (down/up/right/left cursor) to move the
zoomed image around the screen.
5 Press ENTER/OK and only the zoomed picture will
show on the screen.
6 Press to exit zoom mode and return to normal
playback.
7 Press SYSTEM MENU to remove the system menu
bar.
Shuffle
DVD Discs
This shuffles the playing order of chapters within a title, if
the title has more than one chapter.
1 Press SHUFFLE during playback.
2 To return to normal playback, press SHUFFLE again.
Video CDs
This shuffles the playing order of tracks within a disc, if the
disc has more than one tracks.
1 Press SHUFFLE during playback.
2 To return to normal playback, press SHUFFLE again.
Special DVD+RW/+R features
Recording date and time
If a recording was made from a digital video camera using
the i.LINK DV input, the original recording date and time
are automatically stored as DVD subtitles.
● Press SUBTITLE to display the recording date and
time.
➤ The recording date and time are displayed in the
right bottom corner of the screen.
Special DVD-Video features
Menus on the disc
Some DVDs include disc menus for Title or Chapter
selection or special playback features. You can make
selections from these menus.
Title menus
1 Press TOP MENU.
➤ If the current title has a menu, the menu will appear
on the screen. Otherwise, the disc menu will be
displayed.
2 The menu can list camera angles, spoken language and
subtitle options, and chapters for the title.
Press the appropriate numerical button to choose a
numbered item or use w/v/u/t (down/up/right/left
cursor) to highlight your selection, then press
ENTER/OK.
3 To exit the menu, press TOP MENU again.
Note:
Most DVDs do not have separate disc and title menus.
Disc menu
If a DVD-Video disc has separate disc and title menus, you
can navigate to the disc menu as follows:
press OK to pan
14:30
31/ 08/ 2001
