40 MANAGING DISC CONTENT (DVD+RW/+R ONLY)
Managing disc content (DVD+RW/+R only)
Title settings
You can change each title on the DVD+RW/+R to your
personal preference in the title settings menu.
1 Stop disc playback if necessary. In the Index Picture
Screen, select the required title with w/v (down/up
cursor).
2 Press u (right cursor) to enter the title settings menu
for that title.
3 Use w/v (down/up cursor) to select the item you
wish to change, then follow the steps as directed
below.
Changing name of a recording
Perform steps 1, 2 and 3 as explained above.
4 Press u (right cursor) to select Name.
5 Enter the new name. A name may contain a maximum
of 64 characters.
● Use t/u (left/right cursor) for the position of the
characters. Use w/v (down/up cursor) to change
characters.
● Use SELECT to toggle between capital and lower
case characters.
● Use CLEAR to erase a character.
6 Confirm by pressing ENTER/OK.
Play full title
Perform steps 1, 2 and 3 as explained above.
4 Press u (right cursor) to select ‘Play full title.’
When this item is selected, the title will be played in full,
including hidden chapters, beginning immediately.
Follow the instructions on the screen. (See ‘Operation -
Managing disc content - Editing’)
Erase this title
You may simply erase a title by recording over it,
but if you want to erase the whole title instantly,
do the following:
Perform steps 1, 2 and 3 as explained above.
4 Press u (right cursor) to select ‘Erase this title,’ then
press ENTER/OK.
➤ The message ‘This will completely erase this title,’
‘Press OK to confirm’ is shown.
5 Press ENTER/OK a second time.
➤ ‘Erasing title’ is shown until the action is completed.
➤ After the title has been erased, the Index Picture
Screen will show an empty space instead of the Title. If
there was an empty space in front of or behind this
title, then these are combined into one empty space.
Empty spaces of less than one minute will not be
shown.
Disc Information Screen
1 When in the Index Picture Screen, press .
➤ This selects the first title on the DVD+RW.
2 Press v (up cursor).
➤ You enter the Disc Information Screen.
3 Press w (down cursor) to exit the Disc Information
Screen and return to the Index Picture Screen.
The Disc Information Screen contains the fol-
lowing information:
Settings for soccer
soccer
Name
Play full title
Erase this title
NTSC
DVD playback
Unlocked
Edits
Summer holiday
02:05:10used
Sun 12 13 9 9
11: 13 pm
012
4
Compatibility status
- indicates compatibility of any edits
with DVD players
Video system
- PAL or SECAM
- NTSC
Disc description
- disc name
- total recording duration so far
- date of last recording
Cue to go back to the
Index Picture Screen
Disc status
- unlocked
- locked
- finalized
