TD-W8950ND 150Mbps Wireless Lite N ADSL2+ Modem Router User Guide

¾ Virtual Server Table: The table indicates the information about the Virtual Server entries.

• Server Name: This is the name of the Virtual Server. It is exclusive and must be filled in.

• External Port Start: The base number of External Ports. You can type a service port or

leave it blank.

• External Port End: The end number of External Ports. You can type a service port or leave

it blank.

• Protocol: The protocol used for this application, TCP, UDP, or TCP/UDP.

• Internal Port Start: The base number of Internal Ports. You can type a service port or leave

it blank.

• Internal Port End: The end number of Internal Ports. You can type a service port or leave it

blank.

• Server IP Address: The IP Address of the PC providing the service application.

• Remote Host: The PC can enjoy the service application.

¾ Add: Click the Add button to add a new entry.

¾ Remove: Select the check box in the table (shown in Figure 4-32) and then click the Remove

button, then the corresponding entry will be deleted in the table.

To add a virtual server entry:

1. Click the Add button on the preceding screen Figure 4-32, and then you will see the new

Virtual Server in the next screen as shown in Figure 4-33.

Figure 4-33
