DIS-200G Series Gigabit Ethernet Switch CLI Reference Guide
101
24-2
show cpu-protect safeguard
This command is used to display the settings and status of the Safeguard Engine.
show cpu-protect safeguard
Parameters
None.
Default
None.
Command Mode
EXEC Mode or Any Configuration Mode.
Command Default Level
Level: 1.
Usage Guideline
This command is used to display the settings and status of the Safeguard Engine.
Example
This example shows how to display the settings and current status of the Safeguard Engine.
Switch# show cpu-protect safeguard
Safeguard Enfine State : Disabled
Safeguard Enfine Status : Normal
Utilization Thresholds:
Rising : 60%
Falling : 40%
Switch#
Display Parameters
Safeguard Engine Status
Displays the current mode that CPU utilization stays. The possible
displayed strings are:
Exhausted: If the CPU utilization is higher than the configured
rising threshold, it will enter Exhausted Mode and Safeguard
Engine will take actions. The Safeguard Engine mechanism
ceases till the utilization is lower than the falling threshold.
Normal: The Safeguard Engine is not triggered to take actions.
