DIS-200G Series Gigabit Ethernet Switch CLI Reference Guide
167
Appendix B - Trap Entries
The following table lists all possible trap log entries and their corresponding meanings that will appear in the
switch.
Authentication Fail
Trap Name
Description
OID
authenticationFailure
An authenticationFailure trap signifies that the
SNMPv2 entity, acting in an agent role, has received a
protocol message that is not properly authenticated.
While all implementations of the SNMPv2 must be
capable of generating this trap, the
snmpEnableAuthenTraps object indicates whether this
trap will be generated.
1.3.6.1.6.3.1.1.5
.5
LBD
Trap Name
Description
OID
isLbdLoopOccurred
his trap is sent when an interface loop occurs.
Binding objects:
(1) isLbdNotifyInfoIfIndex
1.3.6.1.4.1.171.
11.155.1000.46.
0.1
isLbdLoopRestart
This trap is sent when an interface loop restarts after
the interval time.
Binding objects:
(1) isLbdNotifyInfoIfIndex
1.3.6.1.4.1.171.
11.155.1000.46.
0.2
LLDP
Trap Name
Description
OID
lldpRemTablesChange
A lldpRemTablesChange notification is sent when the
value of lldpStatsRemTableLastChangeTime changes. It
can be utilized by an NMS to trigger LLDP remote
systems table maintenance polls.
Binding objects:
(1) lldpStatsRemTablesInserts
(2) lldpStatsRemTablesDeletes
(3) lldpStatsRemTablesDrops
(4) lldpStatsRemTablesAgeouts
1.0.8802.1.1.2.
0.0.1
STP
Trap Name
Description
OID
newRoot
The newRoot trap indicates that the sending agent has
become the new root of the Spanning Tree; the trap is
sent by a bridge soon after its election as the new root,
1.3.6.1.2.1.17.0.
1
