DIS-200G Series Gigabit Ethernet Switch CLI Reference Guide
47
12-2
ip igmp snooping querier
This command is used to enable the capability of the entity as an IGMP querier. Use the
no
form of
this command to disable the querier function.
ip igmp snooping querier
no ip igmp snooping querier
Parameters
None.
Default
By default, this option is disabled.
Command Mode
VLAN Configuration Mode.
Command Default Level
Level: 15.
Usage Guideline
If the system can play the querier role, the entity will listen for IGMP query packets sent by other devices. If
IGMP query message is received, the device with lower value of IP address becomes the querie r.
Example
This example shows how to enable the IGMP snooping querier on VLAN 1.
Switch# configure terminal
Switch(config)# vlan 1
Switch(config-vlan)# ip igmp snooping querier
Switch(config-vlan)#
12-3
ip igmp snooping static-group
This command is used to configure an IGMP snooping static group. Use the
no
form of this command
to delete a static group.
ip igmp snooping static-group
GROUP-ADDRESS
interface
INTERFACE-ID
[,|-]
no ip igmp snooping static-group
GROUP-ADDRESS
[interface
INTERFACE-ID
[,|-]]
Parameters
GROUP-ADDRESS
Specifies an IP multicast group address.
INTERFACE-ID
(Optional) Specifies an interface or an interface list. The interface
should be the physical interface.
,
(Optional) Specifies a series of interfaces, or a separate a range
of interfaces from a previous range. No space is allowed before
and after the comma.
