DIS-200G Series Gigabit Ethernet Switch CLI Reference Guide
165
SNMP
Log Description
Severity
Event Description: SNMP request received with invalid community string
Log Message: SNMP request received from <ipaddr> with invalid community string.
Parameters Description:
ipaddr: The IP address.
Informational
Telnet
Log Description
Severity
Event description: Successful login through Telnet.
Log Message: Successful login through Telnet (Username: <username>, IP:
<ipaddr>)
Parameters description:
ipaddr: The IP address of telnet client.
username: the user name that used to login telnet server.
Informational
Event description: Login failed through Telnet.
Log Message: Login failed through Telnet (Username: <username>, IP: <ipaddr>)
Parameters description:
ipaddr: The IP address of telnet client.
username: the user name that used to login telnet server.
Warning
Event description: Logout through Telnet.
Log Message: Logout through Telnet (Username: <username>, IP: <ipaddr>)
Parameters description:
ipaddr: The IP address of telnet client.
username: the user name that used to login telnet server.
Informational
Event description: Telnet session timed out.
Log Message: Telnet session timed out (Username: <username>, IP: <ipaddr>).
Parameters description:
ipaddr: The IP address of telnet client.
username: the user name that used to login telnet server.
Informational
Voice-VLAN
Log Description
Severity
Event description: When a new voice device is detected on an interface.
Log Message: New voice device detected (<interface-id>, MAC: < mac-address >)
Parameters description:
interface-id: Interface name.
mac-address: Voice device MAC address
Informational
Event description: When an interface which is in auto voice VLAN mode joins the
voice VLAN
Log Message: < interface-id > add into voice VLAN <vid >
Parameters description:
interface-id: Interface name.
vid:VLAN ID
Informational
Event description: When an interface leaves the voice VLAN and at the same time,
no voice device is detected in the aging interval for that interface, the log message
will be sent.
Log Message: < interface-id > remove from voice VLAN <vid >
Parameters description:
Informational
