Hardware Installation - 10 -
1-2 Product Specications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
5200 MT/s
Chipset
North Bridge: AMD 770
South Bridge: AMD SB710
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1666 (O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
Support for ECC memory modules
(Note 2)
Audio
Realtek ALC888 codec
High Denition Audio
2/4/5.1/7.1-channel
(Note 3)
Support for S/PDIF In/Out
Support for CD In
LAN
1 x Realtek RTL8111C/D chips (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
4 x PCI Express x1 slots
2 x PCI slots
Storage Interface
South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
USB
South Bridge
:
- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
