BIOS Setup - 44 -
2-6 Integrated Peripherals
OnChip IDE Channel
Enables or disables the integrated IDE controller. (Default: Enabled)
OnChip SATA Controller (AMD SB710 Chipset)
Enables or disables the SATA controller integrated in the AMD SB710 chip. (Default: Enabled)
OnChip SATA Type (AMD SB710, SATA2_0~SATA2_3 connectors)
Congures the operating mode of the integrated SATA2_0~SATA2_3 controller.
Native IDE Allows the SATA controller to operate in Native IDE mode. (Default)
Enable Native IDE mode if you wish to install operating systems that support Native
mode.
RAID Enables RAID for the SATA controller.
AHCI Congures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specication that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
OnChip SATA Port4/5 Type (AMD SB710, SATA2_4~SATA2_5 connectors)
This option is congurable only when OnChip SATA Type is set to RAID or AHCI. Congures the oper-
ating mode of the integrated SATA2_4/SATA2_5 connectors.
IDE Disables RAID for the SATA controller and congures the SATA controller to PATA
mode. (Default)
As SATA Type The mode depends on the OnChip SATA Type settings.
Onboard LAN Function
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
OnChip IDE Channel [Enabled]
OnChip SATA Controller [Enabled]
OnChip SATA Type [Native IDE]
x OnChip SATA Port4/5 Type IDE
Onboard LAN Function [Enabled]
Onboard LAN Boot ROM [Disabled]
SMART LAN [Press Enter]
Onboard Audio Function [Enabled]
Onchip USB Controller [Enabled]
USB EHCI Controllers [Enabled]
USB Keyboard Support [Enabled]
USB Mouse Support [Disabled]
Legacy USB storage detect [Enalbed]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
