Create Arrays Manually

To create a new array, press <2> to enter the Dene LD Menu window (Figure 4). The Dene LD selection

from the Main Menu allows users to begin the process of manually dening the drive elements and RAID

levels for one or multiple disk arrays.

In Figure 4, use the up or down arrow key to move to a logical disk set and press <Enter> to enter the RAID

conguration menu (Figure 5).

Figure 4

Figure 5

LD 4 ---- ---- ----- ----

LD 5 ---- ---- ----- ----

LD 6 ---- ---- ----- ----

LD 7 ---- ---- ----- ----

LD 8 ---- ---- ----- ----

LD 9 ---- ---- ----- ----

LD 10 ---- ---- ----- ----

[

h

] Up [

i

] Down [ESC] Exit [Enter] Select

LD No RAID Mode Total Drv

LD 1 RAID 0 0

Stripe Block: 64 KB Fast Init: ON

Gigabyte Boundary: ON Cache Mode: WriteThru
