General accessories

MS1xx, MO1xx, MS5100, MO5100, MS49x, MO49x

Description

With this solution of door coupling rotary mechanism it is possible to operate a manual motor starter in the

back of a switch cabinet from outside. The door coupling mechanism prevents opening of the door of a

switch cabinet with the manual motor starter in ON position.

The complete mechanism includes handle, shaft, driver, shaft alignment ring and shaft supporter.

qty

(1 pce)

mm

pcs kg

Shafts

MS116,

MS132,

MO132,

MS165,

MO165,

MS4xx,

For MSHD handles. Shaft di-

ameter 6mm. Shaft extension

for door coupling driver.

85 OXS6X85 1SCA101647R1001 1 0.020

MS132,

MO132,

MS165,

MO165,

MS4xx,

MO4xx

with bail diameter 5 … 8 mm,

door interlock in ON position

defeatable, for use with 6 mm

OXS6…types up to 180 mm or

driver shafts MSOX.

1)

Yellow MSHD-LY

Driver

MS116,

MS132,

MO132,

MS165,

MO165,

MS4xx,

MO4xx

Coupling driver for use with

6mm OXS6… types up to

180 mm.

MS165,

MO165,

MS4xx,

MO4xx

panel doors more easy. Use for

OXS6X > 105 mm.

Shaft supporter

MS116,

MS132,

MO132

With the MSAH it is possible

to support the shaft in the

extension of handle (MSHD). It

is mandatory for the usage of

shafts >130 mm.

5)

1)

2)

3)

4)

MSMN

MSH-AR

MSAH1

RHD Normal Direct

Handle
