Chapter 12 Warning Codes|C200 Series

12-1

Chapter 12 Warning Codes

CE01

Comm. Error 1

Warning

Display error signal

Abbreviate error code.

The code is displayed as shown on KPC-CE01

Display error description

Display on

KPE-LE02

Display on

KPC-CC01

Descriptions

SE1

Save Error 1

Warning

Keypad COPY error 1

SE2

Save Error 2

Warning

Keypad COPY error 2

SE3

Copy Model Err 3

Warning

Keypad COPY error 3

PID

PID FBK Error

Warning

PID feedback error

nalog loss

Warning

ACI signal error

When Pr03-19 is set to 1 and 2.

Under Current

Warning

Low current

PGFb

PG FBK Warn

Warning

PG feedback error

PGL

PG Loss Warn

Warning

PG feedback loss

oSPd

Over Speed Warn

Warning

Over-speed warning
