Chapter 10 Summary of Parameter Settings|C200 Series
10-4
Parameter Explanation
Settings
Factory
Setting
00-31
Source of the Operation
Command （HAND）
0: Digital keypad
1: External terminals. Keypad STOP disabled.
2: RS-485 serial communication. Keypad STOP
disabled.
3: CANopen communication card
0
00-32
Digital Keypad STOP
Function
0: STOP key disable
1: STOP key enable
0
00-33
~
00-47
Reserved
00-48 Display Filter Time (Current)
0.001~65.535 sec
0.100
00-49 Display Filter Time (Keypad)
0.001~65.535 sec
0.100
00-50 Software Version (date)
Read only
#####
