Chapter 7 Optional Accessories|C200 Series
7-5
Fuse Specification Chart
Use only the fuses comply with UL certificated.
Use only the fuses comply with local regulations.
Model Manufacturer Class / Catalog No Rating
VFD004CB21A-20/-21/-21M Class _T / JJN-15 300 Vac, 15A
VFD007CB21A-20/-21/-21M Class _T / JJN-20 300 Vac, 20A
VFD015CB21A-20/-21/-21M Class _T / JJN-30 300 Vac, 30A
VFD022CB21A-20/-21/-21M Class _T / JJN-50 300 Vac, 50A
VFD004CB23A-20/-21/-21M Class _T / JJN-10 300 Vac, 10A
VFD007CB23A-20/-21/-21M Class _T / JJN-15 300 Vac, 15A
VFD015CB23A-20/-21/-21M Class _T / JJN-20 300 Vac, 20A
VFD022CB23A-20/-21/-21M Class _T / JJN-30 300 Vac, 30A
VFD037CB23A-20/-21/-21M Class _T / JJN-40 300 Vac, 40A
VFD007CB43A-20/-21/-21M Class _T / JJS-10 600 Vac, 10A
VFD015CB43A-20/-21/-21M Class _T / JJS-10 600 Vac, 10A
VFD022CB43A-20/-21/-21M Class _T / JJS-15 600 Vac, 15A
VFD037CB43A-20/-21/-21M Class _T / JJS-20 600 Vac, 20A
VFD040CB43A-20/-21/-21M Class _T / JJS-20 600 Vac, 20A
VFD055CB43A-20/-21/-21M Class _T / JJS-30 600 Vac, 30A
VFD075CB43A-20/-21/-21M
Cooper Bussmann Inc.
Class _T / JJS-40 600 Vac, 40A
