Chapter 10 Summary of Parameter Settings|C200 Series
10-13
Parameter Explanation Settings
Factory
Setting
03-41
keypad potentiometer
Positive/negative Bias
Mode
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving
as the center
4: Serve bias as the center
0
03-42
keypad potentiometer
Input Gain
-500.0~500.0% 100.0
03-43
keypad potentiometer
Analog Input Filter Time
0~2.00 sec. 0.01
03-44
~
03-49
Reserved
03-50
Analog Input Curve
Selection
0: Regular Curve
1: 3 point curve of AVI
2: 3 point curve of ACI
3: 3 point curve of AVI & ACI
4: 3 point curve of AUI
5: 3 point curve of AVI & AUI
6: 3 point curve of ACI & AUI
7: 3 point curve of AVI & ACI & AUI
0
03-51 AVI Low Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
0.00
03-52 AVI Proportional Low Point 0.00~100.00% 0.00
03-53 AVI Mid Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
5.00
03-54 AVI Proportional Mid Point 0.00~100.00% 50.00
03-55 AVI High Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
10.00
03-56
AVI Proportional High
Point
0.00~100.00% 100.00
03-57 ACI Low Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
4.00
03-58
ACI Proportional Low
Point
0.00~100.00% 0.00
03-59 ACI Mid Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
12.00
03-60 ACI Proportional Mid Point 0.00~100.00% 50.00
03-61 ACI High Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
20.00
03-62
ACI Proportional High
Point
0.00~100.00% 100.00
03-63
Positive AUI Voltage Low
Point
0.00~10.00V 0.00
03-64
Positive AUI Voltage
Proportional Low Point
0.00~100.00% 0.00
03-65
Positive AUI Voltage Mid
Point
0.00~10.00V 5.00
03-66
Positive AUI Voltage
Proportional Mid Point
0.00~100.00% 50.00
03-67
Positive AUI Voltage High
Point
0.00~10.00V 10.00
03-68
Positive AUI Voltage
Proportional High Point
0.00~100.00% 100.00
03-69
Negative AUI Voltage Low
Point
0.00~ -10.00V 0.00
