Chapter 10 Summary of Parameter Settings|C200 Series
10-5
01 Basic Parameters
Parameter Explanation Settings
Factory
Setting
01-00 Max. Operation Frequency
0.00~600.00Hz
60.00/
50.00
01-01 Output Frequency of Motor 1 0.00~600.00Hz
60.00/
50.00
01-02 Output Voltage of Motor 1
230V: 0.0V~255.0V
460V: 0.0V~510.0V
200.0
400.0
01-03
Mid-point Frequency 1 of
Motor 1
0.00~600.00Hz 3.00
01-04 Mid-point Voltage 1 of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
11.0
22.0
01-05
Mid-point Frequency 2 of
Motor 1
0.00~600.00Hz 0.50
01-06 Mid-point Voltage 2 of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
2.0
4.0
01-07
Min. Output Frequency of
Motor 1
0.00~600.00Hz 0.00
01-08 Min. Output Voltage of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
0.0
0.0
01-09 Start-Up Frequency 0.00~600.00Hz 0.50
01-10 Output Frequency Upper Limit 0.00~600.00Hz 600.00
01-11 Output Frequency Lower Limit 0.00~600.00Hz 0.00
01-12 Accel. Time 1
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-13 Decel Time 1
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-14 Accel Time 2
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-15 Decel Time 2
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-16 Accel Time 3
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-17 Decel Time 3
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-18 Accel Time 4
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-19 Decel Time 4
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-20 JOG Acceleration Time
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-21 JOG Deceleration Time
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0
01-22 JOG Frequency 0.00~600.00Hz 6.00
01-23 1st/4th Accel/decel Frequency 0.00~600.00Hz 0.00
01-24
S-curve Acceleration Begin
Time 1
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
01-25
S-curve Acceleration Arrival
Time 2
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
01-26
S-curve Deceleration Begin
Time 1
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
01-27
S-curve Deceleration Arrival
Time 2
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
01-28
Skip Frequency 1 (upper limit)
0.00~600.00Hz 0.00
01-29
Skip Frequency 1 (lower limit)
0.00~600.00Hz 0.00
