Delta Electronics VFD015CB23A-21M [83/363] Multi step speed parameters
![Delta Electronics VFD007CB23A-21 [83/363] Multi step speed parameters](/views2/1567795/page83/bg53.png)
Chapter 10 Summary of Parameter Settings|C200 Series
10-15
04 Multi-step Speed Parameters
Parameter Explanation Settings
Factory
Setting
04-00 1st Step Speed Frequency 0.00~600.00Hz 0
04-01
2nd Step Speed
Frequency
0.00~600.00Hz
0
04-02
3rd Step Speed
Frequency
0.00~600.00Hz
0
04-03 4th Step Speed Frequency
0.00~600.00Hz
0
04-04 5th Step Speed Frequency
0.00~600.00Hz
0
04-05 6th Step Speed Frequency
0.00~600.00Hz
0
04-06 7th Step Speed Frequency
0.00~600.00Hz
0
04-07 8th Step Speed Frequency
0.00~600.00Hz
0
04-08 9th Step Speed Frequency
0.00~600.00Hz
0
04-09
10th Step Speed
Frequency
0.00~600.00Hz
0
04-10
11th Step Speed
Frequency
0.00~600.00Hz
0
04-11
12th Step Speed
Frequency
0.00~600.00Hz
0
04-12
13th Step Speed
Frequency
0.00~600.00Hz
0
04-13
14th Step Speed
Frequency
0.00~600.00Hz
0
04-14
15th Step Speed
Frequency
0.00~600.00Hz
0
