Verto 50G529 [10/64] Operation settings

• Turn the wheel lock of the additional handle (7) clockwise to

clamp the handle.

DEPTH GAUGE INSTALLATION

Depth gauge rod (8) is used to limit the depth of drill penetration

in material.

• Loosen the wheel lock, which blocks collar of the additional

handle (7).

• Slide depth gauge rod (8) into the hole in the additional handle

collar.

• Set desired drilling depth.

• Fix by tightening the wheel lock of the additional handle (7) collar.

INSTALLATION OF WORKING TOOLS

Disconnect the power tool from power supply.

• Insert key into one of the holes on the circumference of the drill

chuck (1).

• Open jaws to desired dimension.

• Insert cylindrical drill shank into the drill chuck (1), push it to the

limit.

• Tighten jaws on drill shank with the key (insert it into three holes

on the drill chuck circumference).

Remember to always remove the key from the chuck after you

finish drill installation or removal.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the label of the

drill.

Switching on – press the switch button (6) and hold in this position.

Switching off – release pressure on the switch (6).

Locking the switch (continuous operation)

Switching on:

• Press the switch button (6) and hold in this position.

• Press the switch lock button (3) (fig. A).

• Release pressure on the switch (6).

Switching off:

Press and release the switch (6).

Range of rotational speed of the spindle is controlled with

pressure on the switch button.

WHEEL FOR SPINDLE ROTATIONAL SPEED CONTROL

The drill allows for operation with different spindle speeds. It can

be controlled with the wheel (5) (fig. A). For each setting of the

wheel for speed control, the speed can be adjusted continuously by

increasing or decreasing pressure on the switch button (6).

• Increase the speed by turning the wheel (5) clockwise.

• Reduce the speed by turning the wheel (5) counter-clockwise.

* Refer to graphic symbols on the wheel for rotational speed control or the switch.

Choose proper rotational speed when the drill operates with no

load, with pressed switch lock button. Defined speed may decrease

under load.

LEFT – RIGHT DIRECTION OF ROTATION

Choose direction of spindle rotation with the selector switch (4)

(fig. A).

Clockwise rotation – set the switch (4) to the extreme left position.

Counter clockwise rotation – set the switch (4) to the extreme right

position.

* In certain cases position of the direction selector switch relating to rotation

direction may be different than specified. Please refer to graphic signs placed on

the switch or tool body.

Do not change direction of rotation when the spindle of the drill

is rotating. Check if the position of the selector switch is correct

before starting the tool.

OPERATION MODE SWITCH

Operation mode switch (2) allows for choosing suitable work mode:

drilling with or without impact (fig. B). Set the operation mode

switch in the position for drilling without impact (drill symbol),

when processing materials like metal, wood, ceramics, plastics and

alike. Set the operation mode switch in the position for drilling with

impact (hammer symbol), when processing materials like stone,

concrete, brick and alike. Holes in wood, wood-like materials and

metals are made with drills of high speed steel or carbon steel (the

latter for wood and wood-like materials only). For stroke drilling

special drills with sintered carbide inserts should be used.

You should not use counter clockwise rotation when impact

function is on.

Long lasting drilling at low rotational speed of the spindle

may cause motor overheating. Provide regular breaks during

operation or let the tool operate at maximum speed with no load

for approximately 1–2 minutes. Do not cover holes for motor

ventilation in the tool body.

OPERATION AND MAINTENANCE

Unplug the power cord from the mains socket before

commencing any activities related to installation, adjustment,

repair or maintenance.

MAINTENANCE AND STORAGE

• Cleaning the device after each use is recommended.

• Do not use water or any other liquid for cleaning.

• Clean the tool with a dry cloth or blow through with compressed

air at low pressure.

• Do not use any cleaning agents or solvents, they may damage

plastic parts.

• Clean ventilation holes in the motor casing regularly to prevent

device overheating.

• In case of power cord damage replace it with a cord with the same

specification. Entrust the repair to a qualified specialist or return

the tool to a service point.

• In case of excessive commutator sparking, have the technical

condition of carbon brushes of the motor checked by a qualified

person.

• Always store the tool in a dry place, beyond reach of children.

DRILL CHUCK REPLACEMENT

• Open chuck (1) jaws.

• Unscrew the chuck fixing screw with cross screwdriver, by turning

it clockwise (left-hand thread).

• Install hex key in the chuck (fig. D).

• Gently tap free end of the hex key.

• Unscrew the chuck.

Installation of the chuck is similar to deinstallation, only the

sequence of actions is reversed.

REPLACEMENT OF CARBON BRUSHES

Replace immediately used up (shorter than 5 mm), burnt or

cracked motor carbon brushes. Always replace both brushes at

a time.

Entrust replacement of carbon brushes only to a qualified

person. Only original parts should be used.

All faults should be repaired by service workshop authorized by the

manufacturer.
