10
avoid contact with the substance. In case of accidental contact, flush
the electrolyte abundantly with water. In case of contact with eyes,
additionally seek medical attention. Leaked electrolyte may cause eye
irritation or burns.
• Do not disassemble the battery – there is a risk of short circuiting.
• Do not use power tool battery in rain.
• Always keep the battery away from sources of heat. Do not leave
the battery for a long time in high temperature (in direct sunlight, in
proximity of heaters and wherever the temperature exceeds 50°C).
SAFETY INSTRUCTIONS FOR BATTERY CHARGER
• This equipment is not intended for use by persons with restricted
physical, sensory or mental capabilities (including children) or persons
who have no experience or are unfamiliar with the equipment, unless
the use is supervised or carried out in accordance with equipment use
instructions handed over by persons responsible for their safety.
• Pay attention to children so they don’t play with the equipment.
• Do not expose the charger to humidity or water. Ingress of water
into the charger increases risk of electric shock. Use the charger only
in dry rooms.
• Disconnect the charger from power supply before starting any
maintenance or cleaning.
• Do not use charger when placed on ammable surface (e.g. paper,
textiles) or in proximity of ammable substance. Greater charger
temperature when charging increases risk of fire.
• Check condition of charger, cable and plug before each use.
Do not use the charger if any damage is found. Do not try
to disassemble the charger. All repairs should be made by an
authorized service workshop. Improper charger assembly may cause
electric shock or fire.
• Children and persons who are physically, emotionally or mentally disabled
and other persons, whose experience or knowledge is insufficient to use
the charger while following all safety rules should not use the charger
without supervision of person responsible for their safety. Otherwise there
is a risk of improper use and injuries in consequence.
• When the charger is not in use, it should be disconnected from the
mains network.
CAUTION! The design is assumed to be safe, protection measures
and additional safety systems are used, nevertheless there is always
a small risk of injuries at work.
Li-Ion batteries may leak, set on re or explode when heated to high
temperature or short-circuited. Do not store the batteries in a car
in hot and sunny days. Do not open the battery. Li-Ion batteries
contain electronic protection devices that, if damaged, may cause
re or explosion of the battery.
EXPLANATION OF USED SYMBOLS
12 4
6
35
78910
11 12 13 14 15
16 17 18
360°
19
20
1. CAUTION! Use precaution measures.
2,3. Read instruction manual, observe warnings and safety
conditions therein!
4. Use personal protection equipment (protective goggles, earmuff
protectors).
5. Remove the battery from the device before starting any
adjustments or cleaning related tasks.
6. Use protective gloves
7. Keep the tool away from children
8. Use protective clothes
9. The garden tool is designed for outdoors use
10. Do not put your hands or legs close to cutting parts!
11. Keep safe distance from working garden tool
12. Protect the tool from moisture
13. When the device is operating do not put hands into its openings
14. Disconnect the charger before repairs
15. Protection class 2
16. The charger is designed to operate indoors in dry environment
17. Do not throw cells into fire
18. Maximum permissible cell temperature
19. Recycling
20. Do not allow other persons in the grass trimmer operation range
CONSTRUCTION AND USE
Cordless grass trimmer is a battery-powered tool. Drive consists of
DC commutator motor with permanent magnets. Tool of this type is
designed for tasks in home garden. The grass trimmer is designed for
trimming grass in corners and edges of lawns and flowerbeds, wherever
lawn mower cannot reach.
Use the power tool in accordance with the manufacturer’s
instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1. Switch lock button
2. Switch
3. Auxiliary handle
4. Locking buttons for auxiliary handle
5. Battery lock button
6. Battery
7. LED diodes
8. Locking ring for main handle
9. Telescopic pipe
10. Locking ring for telescopic pipe
11. Guide with wheels
12. Head
13. Locking button for head tilt angle
14. Edge rod
15. Guard
16. Line lock button
17. Cutting line
18. Metal blade
19. Safety catches
20. Cover
21. Spool casing
22. Spool
* Differences may appear between the product and drawing
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Guard with screws - 1 set
2. Edge rod - 1 pce
3. Guide with wheels - 1 pce
4. Battery - 2 pcs
**
5. Charger - 1 pce**
** Optional equipment is included only in devices 52G506, 52G549, 52G568, 52G585.
Devices 52G506-0, 52G549-0, 52G568-0, 52G585-0 do not contain the abovementioned
equipment.
All VES (VERTO ENERGY SYSTEM) batteries and chargers are compatible
with VERTO devices: 52G506, 52G506-0, 52G549, 52G549-0, 52G568,
52G568-0, 52G585, 52G585-0.
