EMOTRON DSV 5445/5444
Page 2
Emotron 21.04.09
Dear customer / user,
System DSV 5445 - Lift offers you a high-quality, modern and very powerful drive concept for old
and new lift and lifting gear systems.
The field oriented system DSV 5445 - Lift can power all common winch types (both with and
without gearing and independent of synchronous or asynchronous technology).
The customer/user should read these instructions carefully and should have understood them
before starting work.
The following products:
DSV 5445 ; DSV 5452 ; DSV 5453 ; DSV 5445/5453-Plus-series
KD 915 , KD 920 ; Fine HF-SET 93251340268 (DSV 5452 incl. movable cubicle) ;
Brake resistors 4...40 Ohm (Type Cressall, Frizlen, Danotherm),
comply with the following directives and standards:
Low voltages directive 73/23/EWG - amendment 93/68/EWG - EMC directive 89/336/EWG, amendments
92/31/EWG and 93/68/EWG, incl. actually EMC directive 2004/108/EG
including the appropriate amendment directives up to date of drawing.
The following standards are used:
EN 60204-1 1998-11 IEC 61000-3-2: 2002-12 EN 55011: 1998
EN 61800-3 pr A.1.1 1999 IEC 61000-3-2/A1: 1997 EN 55011/A1: 1999
EN 61800-3 pr A11 ; 1999 IEC 61000-3-2/A2: 1998 EN 55011/A2: 2000
EN 61800-3 2002-04 EN 61800-2 1999-08 EN 61800-4 2003-08
EN 12015 2004 EN 12016-08 1998
VDE 0660 Part 500 (IEC 439, EN 60439)
EN 61800-6-3 2002-08 EN 55011B
(basic emission standards) incl. IEC801 Part 1-5
VDE 0875 Part 11 2003-08 EN 61000-6-3/AA 2004-07 EN 61800-1 1999-08
Optional on request : EN 954-1 part EN 61508 (not for all products available).
The declaration covers the modules and units delivered by us, but the user must ensure that the machine
complies with the directives applicable to the end product after mounting or installation.
Following the IEEE915 directive line reactors of 4% uk minimum are needed, further information or special
solutions will be projected and quotated on request.
Emotron Lift Center GmbH
Max-Planck-Straße 15
D 72639 Neuffen
Telefon: ++49 (0)7025/101-0
Telefax: ++ 49 (0)7025/5824
eMail: info@emotron.com
http://www.emotron.com
(alt) http://www.dietz-electronic.de
