EMOTRON DSV 5445/5444
Page 36
Emotron 21.04.09
Which .UPD files must one load under which conditions (only for TUDYxxN/TUDXxxN standard lift)?
Program name e.g. suitable for controllers manufactured by:
*3**.KOM/UPD Böhnke+Partner, Osma, High-Content, certain old relay controllers.
not for new development; updates and div. functions are not available.
*7**.KOM/UPD
Kollmorgen, Liftronic, Schneider, NewLift, Wittur, Schmitt&Sohn and other types
(typical standard setting, also runs with High-Content and Böhnke+Partner).
*9**.KOM/UPD International version (separate UP/DOWN signal), otherwise upwards compatible to
"7SZ", updates and div. functions are not available.
*10**.KOM/UPD
****D.KOM/UPD
****A.KOM/UPD
DCP/ACP-bus version, e.g. for Böhnke+Partner, AS, NewLift, Kollmorgen.
Following updates are currently available (only 20...40 MHz – standard lift).
UPD file: Recommended
state
Suitable for: Remarks
7SZ 5442.UPD From 29.03.2000 System 5442-Lift old
3SZ 5442.UPD From 29.03.2000 " " " old
7SZ 5444.UPD From 29.03.2000 System 5444-Lift up to MNo. 192999 old
3SZ 5444.UPD From 29.03.2000 " " " old
LIFT7SZ.UPD From 24.05.2003 System 5444+5445 Lift from MNo. 193000 Standard-Liftprogr.
LIFT7TZ.UPD From 29.10.2007 System 5444+5445 Lift from MNo. 217215 Profi-Liftprogramm
CHINA7TZ.UPD From 15.10.2008 System 5444+5445 Lift from MNo. 217215 Premium-Liftprogr.
LIFT3SZ.UPD From 06.12.2003 " " " old
LIFT9SZ.UPD From 31.01.2002 " " " old
ACP-DCP.UPD From 30.01.2008 " " " from MNo. 205000 Standard-DCP/ACP
The advantage of the updates lies, for example, in the fact that older systems such as DSV 5442/5444 can
be operated with DSV 5445 interactive control or prompts.
The updates for DSV 5442 and the older DSV 5444 devices assume that these systems have already been
configured with the aid of the original program, i.e. are already running.
What is to be considered with older 40 – 50 MHz board:
UPD-files for 50MHz devices (gearless winches and EPM from Alpha only) are partly available
now.
If you wish to update your system without a present UPD-file use the function “Complete transfer...”
and the respective KOM-file. After this you have to accommodate the settings according to the
settings of the old values of your lift system. Use for new parameters/variables the factory settings.
