EMOTRON DSV 5445/5444
Page 40
Emotron 21.04.09
Adr. Variable in FU-Control Remarks TUDY/X TUDZ
E14 Open door at V lower
V If the speed is less than the set value (m/s), then
output A2 is set. At speeds less than the set value,
following lift function is enabled: "Early opening
doors". Remark: 0E14 takes over the switchover of
the I-gain described under 0E12 for technical reasons
with DCP under 50 MHz (Reason: 0E12 may not be
below 0.5 m/s under DCP). Value range: 0.003 -
3.000
0.30 0.30
(Function
E12 and E14
is exchanged
with older
DCP:
0,020)
E16 Excess speed
V If the speed is less than the set value (m/s), then
output A3 is set. V3 must be smaller than E16; the
standard setting 1.05 x V3 = value for 0E16 is
recommended in association with flag set for pointed
arch (0E1A) (fine adjustment of long run to one-floor
run is made here using the value of 0E16). Value
range: 0.300 - 8.000 m/s (FUC=300...8000 mm/s)
Reaching the over speed does not lead to an
automatic fault shut-down (A3 changes to low); if this
is required, A3 must be used as the supply voltage for
the generation of the ISP and/or E0 signals. A3 then
switches the DSV off (brake engagement).
1.050
approx.
1.05 x 'V3'
using new
TUD-
Firmware,
ca. 1.15 x
'V3' using
old
AUD-
Firmware
1.68
approx. 1.05
x 'V3' using
new TUD-
Firmware,
ca. 1.15 x
'V3' using old
AUD-
Firmware
E18 Return Ramp B
V The greater the value, the softer and longer the
braking distance. Special case "0" ➔ B = HL see
point in normal lift instructions,
value range: 0 – 1000.
Remark: At 50 MHz, approx. the factor 10 is included
in the value of the ramp (Reason: The resolution is
better).
45
200
E1A Pointed arch ok=255
V The pointed arch function is activated by the value
0E1A='255'. Only V3 is used for driving (V1, V2 no
longer make a pointed arch as from 22.05.2002 and
can therefore be used separately, since only V3
performs a pointed arch drive).
In connection with 0E02 (V3) and 0E16 (over speed)!
Note: Using ACP/DCP_03 this value should be ’0’, for
DCP_04 value of 0E1A must be set to 255 all time.
0 0
E1C I-part stop and hold
V The I-part stop and hold prevents reverse rotation
during brake is opening. Effective within the speed
threshold 0E12 and at standstill, start value: 8
Value range: 2 - 400
8 8
E1E I-part run
V I-part run replaces function of parameter I (I-gain
normal running)!
Start value: 40, value range: 2 – 400, variable
40 80
E20 Ramp gradient
V Discrease if having elevators with velocities more
than 2m/s in use.
default value = 200; see also in standard lift
manual
Value range:: 10 – 1000
Only for LIFT7TZ with analogue setpoint setting.
Restricts the maximum ramp at analogue setpoint.
200 200
E22 Run-up ramp HL
V The larger the value, the softer and longer the
acceleration; see also point in instructions.
Value range: 10 – 1000 (as for brake ramp 'B')
Remark: At 50 MHz, approx. the factor 10 is included
in the value of the ramp (reason: resolution is better
here).
45 300
